Dahua Technology DH-XVR5216AN-4KL-X 16 Channel Penta-brid 4K 1U Digital Video Recorder

Technical Specification

Features:
  • Make: Dahua Technology
  • Model code: DH-XVR5216AN-4KL-X
  • Channels: 16
  • Hybrid IP inputs: 16+8
  • Inbuilt Multiplexer: Yes
Read more
Additional info:

H.265+/H.265 dual-stream video compression Supports HDCVI/AHD/TVI/CVBS/IP video inputs Max 12/24 channels IP camera inputs, each channel up to 8MP; Max 48/96Mbps Incoming Bandwidth Smart Search and Intelligent Video System

Read more
Make Dahua Technology
Manufacturer Dahua Technology USA Inc.
Model code DH-XVR5216AN-4KL-X
Channels 16
Hybrid IP inputs 16+8
Inbuilt Multiplexer Yes
Storage Capacity GB 10,000
Image per second (IPS) 25/30fps, 50/60fps
Compression Type H.265+/H.265/H.264+/H.264
Resolution 4K
Signal Mode PAL / NTSC
External Storage USB
Recording System HDD
Audio Recording and Properties G.711A, G.711U, PCM
Physical Specifications Dimensions mm: 375 x 287 x 53
Weight kg: 1.5
Electrical Specifications Voltage: 12 V DC
Power Consumption: <20W
Environmental Specifications Operating Temp oC: -10 ~ +55 C (14 ~ 131 F)
Operating Humidity %: 10 ~ 90
Additional info
  • H.265+/H.265 dual-stream video compression
  • Supports HDCVI/AHD/TVI/CVBS/IP video inputs
  • Max 12/24 channels IP camera inputs, each channel up to 8MP; Max 48/96Mbps Incoming Bandwidth
  • Smart Search and Intelligent Video System
Download PDF version Download PDF version
