Bosch NPC-20012-F2WL HD IP CCTV Camera

Technical Specification

Features:
  • Make: Bosch
  • Model code: NPC-20012-F2WL
  • Chip Inch Size: 1/4
  • Digital (DSP): Yes
  • Specialist Type: Infrared
Read more
Additional info:

Bosch NPC-20012-F2WL is a compact IP camera for indoor surveillance. It features 2.5 mm lens, motion/audio detection, cloud services, free viewing Apps & wireless LAN. The built-in microphone and loudspeaker allows remote users to listen in on an area and communicate messages to visitors or intruders via the loudspeaker.

Read more
Make Bosch
Manufacturer Bosch Security Systems
Category Video Surveillance>IP cameras
Model code NPC-20012-F2WL
Chip Inch Size 1/4
Digital (DSP) Yes
Specialist Type Infrared
Sensitivity Lux 0.0
Auto Iris Yes
Direct Drive Yes
Electrical Specifications Voltage: 5 V DC
Power Consumption: 4.4 W
Motion Activated Yes
Focal Length mm 2.5
Mount Type Bracket
Picture Elements HxV 1280 x 720
Network Properties Image Frame Rate: 30 fps
Interface: 10/100 Base-T, auto-sensing, half/full duplex
Network Protocols: IPv4, IPv6, UDP, TCP, HTTP, HTTPS, RTP/ RTCP, IGMP V2/V3, ICMP, ICMPv6, RTSP, FTP, Telnet, ARP, DHCP, NTP (SNTP), SNMP (V1, MIB-II), 802.1x, DNS, DNSv6, DDNS (DynDNS.org, selfHOST.de, noip.com), SMTP, iSCSI, UPnP (SSDP), DiffServ (QoS), LLDP, SOAP, Dropbo
Back Light Compensation Yes
White Balance Yes
Electronic Shutter Range 1/30 ~ 1/150000s
S/ N (Signal/ Noise) Ratio dB > 50
Mini or Compact Yes
Zoom Yes
Compression Type H.264 (MP), M-JPEG
Physical Specifications Dimensions mm: 109 x 65 x 47
Weight g: 105
Environmental Specifications Operating Temperature oC: -10 ~ +40 C (14 ~ +104 F)
Operating Humidity %: 0 ~ 95
HD Yes
Additional info Bosch NPC-20012-F2WL is a compact IP camera for indoor surveillance. It features 2.5 mm lens, motion/audio detection, cloud services, free viewing Apps & wireless LAN. The built-in microphone and loudspeaker allows remote users to listen in on an area and communicate messages to visitors or intruders via the loudspeaker.
