Axis Communications AXIS P1275 Complete, Discreet HDTV 1080p Varifocal Dome

Technical Specification

Features:

Make: Axis Communications
Model code: AXIS P1275
Color Type: Color
Resolution TVL: 1920x1080
Sensitivity lux: 0.22 lux

Additional info:

AXIS P1275 Network Camera is a palm-sized dome that’s designed for surface mounting. It’s excellent for overview or close-up applications. For example, it’s suitable for passport control or security control areas and in banks. It’s also particularly suitable when you want an unobtrusive camera that’s nevertheless visible enough to act as a deterrent.

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	Axis Communications
Manufacturer	Axis Communications
Category	Video Surveillance>IP Dome cameras
Model code	AXIS P1275
Color Type	Color
Resolution TVL	1920x1080
Sensitivity lux	0.22 lux
Dome Type	Fixed
Indoor/Outdoor	Indoor
Mount Type	Surface
Electrical Specifications	Voltage: PoE Power Consumption: Max 4.0 W, typical 2.5 W
Focal length	2.8 - 6.0 mm
Compression	H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles Motion JPEG
White Balance	Yes
Electronic Shutter range	1/32500 to 2 s
Network Properties	Network Protocols: IPv4, IPv6 USGv6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP, MQTT v3.1.1 Image Frame Rate: 25/30fps
Environmental Specifications	Operating Temp ^oC: -20 ~ +50 C (-4 ~ +122 F) Operating Humidity %: 10 ~ 85
Additional info	AXIS P1275 Network Camera is a palm-sized dome that’s designed for surface mounting. It’s excellent for overview or close-up applications. For example, it’s suitable for passport control or security control areas and in banks. It’s also particularly suitable when you want an unobtrusive camera that’s nevertheless visible enough to act as a deterrent.
Download PDF version Download PDF version
