ABLOY CY324T DIN Cylinder With Thumbturn Spindle
Technical Specification
- Make: ABLOY
- Model code: CY324T
- Door Type: Both
- Weight g: 220
High durability cylinder against pulling, twisting and sawing Lock is operated by key from outside and by thumbturn inside the door Suitable for both outer and inner door use Adjustable length with extension system to match different door thicknesses Adjustable locked position of cam
Read more| Make | ABLOY |
|---|---|
| Manufacturer | ASSA ABLOY |
| Category | Access Control>Mechanical digital locks |
| Model code | CY324T |
| Door Type | Both |
| Physical Specifications | Weight g: 220 |
Product description
The ABLOY® CY324T is a high-performance DIN cylinder with a thumbturn spindle, designed for robust security applications. Notable for its resistance to pulling, twisting, and sawing, this cylinder lock offers reliable protection and convenience. One of its key features is the ability to be operated by a key from the outside, while the thumbturn allows for easy access from the inside.
Key Features
- Compatible with a variety of DIN cylinder applications
- Suitable for both external and internal door installations
- Length can be adjusted with an extension system to accommodate different door thicknesses
- Cam's locked position can be customized
- Available in multiple plating finishes, including bright chrome, satin chrome, brushed nickel, bright brass, and satin brass
Technical Specifications
The ABLOY® CY324 is equipped with a range of key systems such as ABLOY PROTEC, ABLOY PROTEC², and ABLOY NOVEL. The external cylinder length options include 31mm for ABLOY PROTEC and PROTEC², and 32.5mm for ABLOY NOVEL. The internal length is consistently 31mm. Additionally, the length of the cylinder is adjustable in increments of 5mm from 31mm to 81mm, and in 10mm steps from 81mm to 131mm.
Ideal Use Cases
The ABLOY® CY324 is ideal for high-security environments requiring durable and versatile locking solutions. It's suited for both residential and commercial buildings, providing effective security for both interior and exterior doors.
