VIVOTEK FD9389-HV H.265 Outdoor Dome Network Camera

Technical Specification

Features:

Make: VIVOTEK
Model code: FD9389-HV
Color Type: Color / Monochrome
Resolution TVL: 2560x1920 (5MP)
Megapixel: Yes

Additional info:

30 fps @ 2560x1920, 60 fps @ 1920x1080 (WDR Pro on) H.265 Compression Technology Smart Stream III to Optimize Bandwidth Efficiency WDR Pro (120 dB) for Unparalleled Visibility in Extremely Bright and Dark Environments SNV (Supreme Night Visibility) for Low Light Conditions Built-in IR illuminators, effective up to 30 meters Smart IR Technology to Avoid Overexposure Trend Micro IoT Security Weather-proof IP66-rated and Vandal-proof IK10-rated Housing

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	VIVOTEK
Manufacturer	VIVOTEK
Model code	FD9389-HV
Color Type	Color / Monochrome
Resolution TVL	2560x1920 (5MP)
Megapixel	Yes
Sensitivity lux	0 ~ 0.06
Indoor/Outdoor	Outdoor
Digital (DSP)	Yes
Electrical Specifications	Voltage: PoE Power Consumption: 8.7 W
Focal length	2.8 mm
Compression	H.265, H.264, MJPEG
Back Light Compensation	Yes
Auto Gain Control	Yes
White Balance	Yes
Electronic Shutter range	1/5 sec. to 1/32,000 sec.
S/ N (Signal/ Noise) Ratio dB	54
Network Properties	Interface: 10 Base-T/100 Base-TX Ethernet (RJ-45) Network Protocols: 802.1X, ARP, CIFS/SMB, CoS, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, PPPoE, QoS, RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS, UDP, UPnP Image Frame Rate: 30 fps
Physical Specifications	Dimensions mm: Ø 129 x 94 Weight g: 610
Environmental Specifications	Operating Temp ^oC: -30 ~ +60 C (-22 ~ +140 F) Operating Humidity %: 90 Protection: IP66, IK10
System Requirments	Operating System: Microsoft Windows 7/8, Mac 10.12 (Chrome only) Web Browser: Chrome 58.0 or above, Internet Explorer 10/11
Additional info	30 fps @ 2560x1920, 60 fps @ 1920x1080 (WDR Pro on) H.265 Compression Technology Smart Stream III to Optimize Bandwidth Efficiency WDR Pro (120 dB) for Unparalleled Visibility in Extremely Bright and Dark Environments SNV (Supreme Night Visibility) for Low Light Conditions Built-in IR illuminators, effective up to 30 meters Smart IR Technology to Avoid Overexposure Trend Micro IoT Security Weather-proof IP66-rated and Vandal-proof IK10-rated Housing
