UltraView UVC-XP3-HR-P 540 TVL WDR Box Camera

Technical Specification

Features:
  • Make: UltraView
  • Model code: UVC-XP3-HR-P
  • Chip Inch Size ": 1/3
  • Color Type: Color / Monochrome
  • Resolution TVL: 540
Read more
Additional info:

The Ultraview UVC-XP3-HR-P is a wide dynamic range 540 TVL box camera with next generation Xposure technology and optional progressive scan output. The camera features easy-to-use five-button menu for setup and configuration.

Read more
Make UltraView
Manufacturer Interlogix
Model code UVC-XP3-HR-P
Chip Inch Size " 1/3
Color Type Color / Monochrome
Resolution TVL 540
Digital (DSP) Yes
Auto Iris Yes
Sensitivity lux 0.5
Lens Mount C/CS
Electrical Specifications Voltage: 11 ~ 30 V DC
Power Consumption: 3.0 W
Wide Dynamic Range Yes
Picture Elements HxV 720 x 540
Auto Gain Control Yes
Gamma Correction 0.36
S/ N (Signal/ Noise) Ratio dB >50
Synchronisation Internal, Line-Lock AC
Signal Mode PAL
Zoom Yes
Video Output Composite 1.0 V p-p at 75 ohms
Physical Specifications Dimension mm: 111 x 74 x 53
Weight g: 411
Environmental Specifications Operating Temperature oC: -10 ~ +60 C (14 ~ 140 F)
Additional info The Ultraview UVC-XP3-HR-P is a wide dynamic range 540 TVL box camera with next generation Xposure technology and optional progressive scan output. The camera features easy-to-use five-button menu for setup and configuration.
Download PDF version Download PDF version
