Interlogix NetworX Intruder Alarm Control Panel

Product Profile

Seamlessly integrating multiple security elements, the NetworX™ system delivers optimum security for current and future needs of your home or small business. Particularly well-suited for new construction, NetworX offers a wide selection of hard-wired security elements including keypad, motion sensors, glassbreak detectors, smoke detectors and magnetic contacts. For added convenience, NetworX has extensive wireless capabilities backed by expert technicians experienced in optimal system design. This system also easily integrates with many third-party control systems such as home automation, lighting, HVAC and audio. Complete with cellular backup, NetworX represents one of the most advanced, expandable and reliable security solutions available.

Control Panels
With a track record of global security success, the NetworX™ product line includes a series of control panels that are universally compatible with all NX products and several GE wired and wireless accessories that can be scaled or modified to meet changing security requirements. The control panel functions as the “brains” of your security system, coordinating input from different sensors and transmitting alarm monitoring information to a central monitoring center. Fully versatile, these control panels accommodate a variety of integrated components that allow you to customize, and easily expand your system to meet your security requirements. All NetworX control panels have fire alarm verification capability to help prevent false alarms.

The NX-4 control panel is a flexible, entry-level security system that features advanced technology for the detection of burglary, fire and environmental events. A cost-effective solution that is easy to install, the NX-4 is ideal for apartments, smaller homes and commercial environments. Equipped with the standard four hard-wired zones, the NX-4 can easily expand to eight fully programmable hard-wired zones, eight wireless zones or a combination of both.

The NX-6 is a full-featured system designed to handle most medium-sized residential and commercial applications. Like all NetworX control panels, its modular design allows for complete integration of multiple systems within one enclosure. In addition to the features found on the NX-4 model, the NX-6 comes standard with six hard-wired zones and can easily expand to 12 fully programmable hard-wired zones, 16 wireless zones or a combination of both.

NX-8 and NX-8E
The NX-8 and NX-8E represent the top-of-the-line systems for the most demanding home and commercial security needs. These feature-rich units include all the capabilities of the NX-6 model with options to accommodate an extensive number of keypads and users.

Read more

Technical Specification

Make NetworX
Manufacturer Interlogix
Model code NetworX Intruder Alarm Control Panel
Control Systems & Kits Yes
Remote Keypad LED
No of Zones 192
Keypad Operated Yes
Additional info NetworX security systems offer 13 different keypad options to meet your specific needs and preferences, including keypads with built-in wireless functionality for simple, convenient setup and operation. The keypad allows you to turn the security system on or off by entering a simple numeric code. Designed with practicality in mind, these keypads complement virtually any décor and feature easy-to-read information displays.
