Messoa SLI08020D High Power Intelligent IR Illuminator

Technical Specification

Features:
  • Make: Messoa
  • Model code: SLI08020D
  • LED Type: IR
  • Distance: 240m / 787ft.
  • Lamp Type: Medium
Read more
Additional info:

The Messoa SLI08020D is a high power intelligent IR illuminator. The adjustable-diffuser technology ensures even light distribution across the entire field of view. It provides the maximum flexibility to adapt to diverse security requirements and the maximum output  performance for long range security applications.

Read more
Make Messoa
Manufacturer MESSOA Technologies Inc.
Model code SLI08020D
LED Type IR
Distance 240m / 787ft.
Lamp Type Medium
Width 20 ~ 60
Filter nM 850
Physical Specifications Dimensions mm: 233 x 310 x 167
Weight kg: 6
Electrical Specifications Voltage: 24 V AC
Power Consumption: 55 W
Environmental Specifications Operating Temperature oC: -50 ~ +60 C (-58 ~ +140 F)
Operating Humidity %: 90
Protection: IP68
Additional info The Messoa SLI08020D is a high power intelligent IR illuminator. The adjustable-diffuser technology ensures even light distribution across the entire field of view. It provides the maximum flexibility to adapt to diverse security requirements and the maximum output  performance for long range security applications.
