Linear INC2DN212E True Day/night Outdoor Camera Package With Mechanical IR Cut-filter

Technical Specification

Features:
  • Make: Linear
  • Model code: INC2DN212E
  • Chip Inch Size ": 1/3
  • Color Type: True Day / Night
  • Resolution TVL: 540 TVL
Read more
Additional info:

Linear INC2DN212E is a true day/night outdoor camera package with mechanical IR cut-filter.

Read more
Make Linear
Manufacturer Linear LLC
Model code INC2DN212E
Chip Inch Size " 1/3
Color Type True Day / Night
Resolution TVL 540 TVL
Digital (DSP) Yes
Auto Iris Yes
Sensitivity lux 0.008
Lens Mount C/CS
Electrical Specifications Voltage: 12 V DC
Power Consumption: < 3.5 W
Focal Length mm 2.8 ~ 12 mm
Mount Type Wall
Picture Elements HxV 752 x 582
White Balance Yes
Electronic Shutter range 1/50 ~ 1/100,000 sec
S/ N (Signal/ Noise) Ratio dB >50
Signal Mode PAL/NTSC
Video Output 1.0 Vp-p, 75 Ohm
Physical Specifications Dimension mm: 60 x 62 x 121
Weight g: 500
Environmental Specifications Operating Temperature oC: -10 ~ +50
Additional info Linear INC2DN212E is a true day/night outdoor camera package with mechanical IR cut-filter.
