LILIN LR6122EX3.6 1080P HD IP Dome Camera

Technical Specification

Features:
  • Make: LILIN
  • Model code: LR6122EX3.6
  • Chip Inch Size: 1/3
  • Color Type: Color / Monochrome
  • Resolution TVL: 1920 x 1080
Read more
Additional info:

LR6122EX3.6 is a HD IP dome camera with full 2 megapixel CMOS image sensor. It has 3D noise reduction, 2D WDR function, and is ONVIF supported.

Read more
Make LILIN
Manufacturer LILIN
Model code LR6122EX3.6
Chip Inch Size 1/3
Color Type Color / Monochrome
Resolution TVL 1920 x 1080
HD Yes
Megapixel Yes
Sensitivity lux 0.25
Indoor/Outdoor Indoor/Outdoor
Digital (DSP) Yes
Electrical Specifications Voltage: 12 VDC
Power Consumption: 10.2 W
Focal length 3.3 ~ 12 mm
Compression H.264 , Motion JPEG
Back Light Compensation Yes
Auto Gain Control Yes
White Balance Yes
Electronic Shutter range 1/30(25)s ~ 1/8000s
Built-in IR LED Yes
Video Output CVBS 1.0Vp-p, 75 ohm, RCA connector
Network Properties Interface: 10Mbps / 100Mbps Base-T, RJ-45
Network Protocols: IP, TCP, UDP, HTTP, SMTP, NTP, DDNS, UPnP, FTP, ARP, DHCP, PPPoE, DNS, RTSP, RTCP, Telnet, ONVIF,ICMP, IGMP
Image Frame Rate: 30 fps
Physical Specifications Dimensions mm: 145 x 130
Weight g: 1,000
Environmental Specifications Operating Temp oC: -35 ~ +50
System Requirments Operating System: Embedded Linux 2.6.32
Web Browser: Windows Internet Explorer 6, 7, 8
Additional info LR6122EX3.6 is a HD IP dome camera with full 2 megapixel CMOS image sensor. It has 3D noise reduction, 2D WDR function, and is ONVIF supported.
Download PDF version Download PDF version
