LILIN IPS2124P Day/night IR IP Dome Camera With 600 TVL Resolution

Technical Specification

Features:

Make: LILIN
Model code: IPS2124P
Chip Inch Size: 1/4
Color Type: Color / Monochrome
Resolution TVL: 600

Additional info:

LILIN IPS2124P is a day/night IR IP dome camera with 600 TVL resolution. The camera features auto focus lens, privacy zone masking, multi-protocol, and horizontal flip. It is ONVIF, iPhone and Android supported.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	LILIN
Manufacturer	LILIN
Category	Video Surveillance>IP Dome cameras
Model code	IPS2124P
Chip Inch Size	1/4
Color Type	Color / Monochrome
Resolution TVL	600
Dome Type	PTZ
Pan Speed ^o/ sec	0.5 ~ 90
Digital (DSP)	Yes
Tilt Speed ^o/ sec	0.5 ~ 90
Electrical Specifications	Voltage: 24 V AC Power Consumption: 13 W
Focal length	3.8 ~ 45.6 mm
Presets	128
Compression	H.264 MP (Main Profile); M-JPEG
Back Light Compensation	Yes
Auto Gain Control	Yes
White Balance	Yes
Electronic Shutter range	1/50 ~ 1/100,000 sec
S/ N (Signal/ Noise) Ratio dB	> 50
Synchronisation	Internal
Signal Mode	PAL
Built-in IR LED	Yes
Video Output	CVBS 1.0 Vp-p / 75 ohms BNC
Zoom Ratio	x12
Network Properties	Interface: 10Mbps / 100Mbps , RJ-45 Network Protocols: IP,TCP,UDP,HTTP,SMTP,ESMTP,NTP,DDNS, FTP,ARP,DHCP,PPPoE,DNS,Telnet,RTP,RTSP,RTCP Control: PTZ Image Frame Rate: 30 fps
Physical Specifications	Dimensions mm: 142 x 135 Weight g: 1,100
Environmental Specifications	Operating Temp ^oC: -10 ~ +50 C (14 ~ 122 F) Operating Humidity %: 0 ~ 90
System Requirements	Operating System: Windows 2000, Windows XP, Windows Vista, Windows 7, Windows 8, Embedded Linux 2.6.9 Web Browser: Windows Internet Explorer 6.0 or above
Additional info	LILIN IPS2124P is a day/night IR IP dome camera with 600 TVL resolution. The camera features auto focus lens, privacy zone masking, multi-protocol, and horizontal flip. It is ONVIF, iPhone and Android supported.
