LILIN IPD2220ES2 2MP HD IP Dome Camera

Technical Specification

Features:

Make: LILIN
Model code: IPD2220ES2
Chip Inch Size: 1/3
Resolution TVL: 2 MP
HD: Yes

Additional info:

LILIN IPD2220ES2 is a 2MP HD IP dome camera. The camera features Face / Tampering / Audio / Motion detection alarm function. It is ONVIF, one-way audio, and digital PTZ supported. It also features 3D noise reduction and 2D WDR function.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	LILIN
Manufacturer	LILIN
Category	Video Surveillance>IP Dome cameras
Model code	IPD2220ES2
Chip Inch Size	1/3
Resolution TVL	2 MP
HD	Yes
Megapixel	Yes
Dome Type	PTZ
Sensitivity lux	0.8
Digital (DSP)	Yes
Electrical Specifications	Voltage: 12 V DC Power Consumption: 4.5 W
Focal length	2.8 mm
Compression	H.264 , Motion JPEG
Back Light Compensation	Yes
Auto Gain Control	Yes
White Balance	Yes
Electronic Shutter range	1/30s ~ 1/8000s
Network Properties	Interface: 10Mbps / 100Mbps Base-T, RJ-45 Network Protocols: IP, TCP, UDP, HTTP, SMTP, NTP, DDNS, UPnP, FTP, ARP, DHCP, PPPoE, DNS, RTSP, RTCP, Telnet, ICMP, IGMP, ONVIF, SNMP Control: ePTZ Image Frame Rate: 30 fps
Physical Specifications	Dimensions mm: 105 x 39 Weight g: 250
Environmental Specifications	Operating Temp ^oC: -25 ~ +50 C (-13 ~ 122 F)
System Requirements	Operating System: Windows 2000, Windows XP, Windows Vista, Windows 7, Windows 8, Embedded Linux 2.6.32 Web Browser: Windows Internet Explorer 6.0 or above
Additional info	LILIN IPD2220ES2 is a 2MP HD IP dome camera. The camera features Face / Tampering / Audio / Motion detection alarm function. It is ONVIF, one-way audio, and digital PTZ supported. It also features 3D noise reduction and 2D WDR function.
