Illustra IES02-B10-BI04 Essentials Gen4 2MP Bullet Camera

Technical Specification

Features:

Make: Illustra
Model code: IES02-B10-BI04
Chip Inch Size: 1/2.8
Color Type: True Day / Night
Resolution: 2MP

Additional info:

2MP (1080p) resolution for HD quality images Manage bandwidth resources with H.264 and H.265 dualstream encoding Dual stream recording, 1080P at 30ips to capture as much detail as possible 2.8mm fixed lens IR Illuminators deliver clear video when viewing dark scenes Factory focused lens for a quick installation IP67 environmental rating to protect against dust and water True Day/Night functionality for low light conditions WDR to simultaneously view high-contrasting areas Supports corridor mode

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	Illustra
Manufacturer	Tyco Security Products
Model code	IES02-B10-BI04
Chip Inch Size	1/2.8
Color Type	True Day / Night
Resolution	2MP
Digital (DSP)	Yes
Specialist Type	Network
Sensitivity Lux	0.08 ~ 0.05
Auto Iris	Yes
Direct Drive	Yes
Electrical Specifications	Voltage: 12 V DC, POE Power Consumption: 8.3 W
High Speed	Yes
Focal Length mm	2.8
Wide Dynamic Range	Yes
Picture Elements HxV	1920 x 1080
Network Properties	Image Frame Rate: 30 ips Interface: IEEE 802.3, 10/100 Base-T/TX, auto sensing, 1 x RJ45 Network Protocols: TCP/IP, IPv4, IPv6, TCP, UDP, HTTP, FTP, DHCP, WS-Discovery, DNS, DDNS, RTP, TLS, Unicast, NTP, SMTP, WSSecurity, IEEE 802.1x, PEAP, SSH, HTTPS, SSL, SOAP, WSAddressing, SNMP, UPnP, RTSP, LLDP
Back Light Compensation	Yes
Auto Gain Control	Yes
White Balance	Yes
Electronic Shutter Range	1/2 ~ 1/10,000s
Signal Mode	NTSC, PAL
Compression Type	H.264, H.265, MJPEG
Physical Specifications	Weight g: 490 Dimensions mm: 77 x 84 x 147
Environmental Specifications	Protection: IP67 Operating Temperature ^oC: -30 ~ 60 C (-22 ~ 140 F) Operating Humidity %: 10 ~ 90
System Requirements	Web Browser: IE 11 or above, Firefox, Chrome, Safari, Microsoft Edge
HD	Yes
Additional info	2MP (1080p) resolution for HD quality images Manage bandwidth resources with H.264 and H.265 dualstream encoding Dual stream recording, 1080P at 30ips to capture as much detail as possible 2.8mm fixed lens IR Illuminators deliver clear video when viewing dark scenes Factory focused lens for a quick installation IP67 environmental rating to protect against dust and water True Day/Night functionality for low light conditions WDR to simultaneously view high-contrasting areas Supports corridor mode
