i-PRO WV-S8543L 3 x 4MP (12MP) Outdoor Multi-Directional Network Camera with AI Engine
Technical Specification
- Make: i-PRO
- Model code: WV-S8543L
- Color Type: Color / Monochrome
- Resolution: 3 x 4MP (12MP)
- Sensitivity Lux: 0.21 to 0.3 lx
3 x 4MP(12MP) 2688x1520 up to 30fps 270° coverage with one IP address Intelligent Auto (with AI Engine) Super Dynamic 108dB Color night vision (0.21 to 0.3 lx) Smart Coding (with AI Engine) Built-in 360° IR LED Remote zoom and focus Continuous view assistance Wide range tilt angle adjustment mechanism Built-in FIPS 140-2 Level 3 Certified Secure Element
Read more| Make | i-PRO |
|---|---|
| Manufacturer | i-PRO |
| Category | Video Surveillance>IP cameras |
| Model code | WV-S8543L |
| Color Type | Color / Monochrome |
| Resolution | 3 x 4MP (12MP) |
| Sensitivity Lux | 0.21 to 0.3 lx |
| Electrical Specifications |
Voltage: 54 V DC / PoE+ Power Consumption: 25.4 W |
| Focal Length mm | 2.9 mm |
| Back Light Compensation | Yes |
| Auto Gain Control | Yes |
| White Balance | Yes |
| Electronic Shutter Range | Max.1/10000s to Max.16/30s |
| Zoom | Yes |
| Network Properties |
Interface: 10Base-T / 100Base-TX / 1000Base-T, RJ45 connector Network Protocols: IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ, LLDP, MQTT IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3, UPnP, IGM |
| Physical Specifications |
Weight g: 3100 Dimensions mm: ø300 x 90 |
| Environmental Specifications |
Protection: IP67/IP66; IK10 Operating Temperature oC: -40 ~ +60 C (-40 ~ +140 F) Operating Humidity %: 10 ~ 100 |
Product description
i-PRO WV-S8543L: Outdoor Multi-Directional Network Camera
The i-PRO WV-S8543L is an advanced outdoor multi-directional network camera engineered for optimum surveillance performance. Equipped with a cutting-edge AI engine, this camera offers comprehensive 270° coverage using only one IP address, streamlining installation and reducing system complexity.
Key Features
- High-Resolution Imaging: Features three 4MP sensors, totalling 12MP, capturing images at 2688x1520 resolution up to 30fps.
- Exceptional Night Vision: With a super dynamic range of 108dB and colour night vision capability from 0.21 to 0.3 lx, it delivers clear images in low-light environments.
- Enhanced Security: Built-in FIPS 140-2 Level 3 Certified Secure Element for robust data protection.
- Smart Features: Intelligent Auto settings, Smart Coding, and AI-powered analytics including AI video motion and audio detection.
- Versatile Adjustment: Wide range tilt angle adjustment mechanism for flexible installation, accommodating various environmental conditions.
Ideal Use Cases
The WV-S8543L is perfect for expansive outdoor areas requiring comprehensive surveillance, such as industrial sites, parking facilities, and public spaces. Its robust weather-resistant design, shock resistance, and temperature tolerance ensure reliable performance in challenging environments.
