Hikvision DS-2CD2385FWD-I 8 MP Network Turret Camera

Technical Specification

Features:
  • Make: Hikvision
  • Model code: DS-2CD2385FWD-I
  • Series: DS-1200KI Series
  • Chip Inch Size: 1/2
  • Color Type: Color / Monochrome
Read more
Additional info:

Up to 8 megapixel high resolution Max. 3840 × 2160@20fps 2.8 mm/4 mm/6 mm/8 mm/12 mm fixed lens, optional H.265, H.265+, H.264+, H.264  •120dB Wide Dynamic Range 3D Digital Noise Reduction DC12V & PoE (802.3af) IR range: up to 30m

Read more
Make Hikvision
Manufacturer Hikvision USA Inc.
Model code DS-2CD2385FWD-I
Series DS-1200KI Series
Chip Inch Size 1/2
Color Type Color / Monochrome
Resolution 8MP
Digital (DSP) Yes
Specialist Type Megapixel
Sensitivity Lux 0 ~ 0.01
Auto Iris Yes
Direct Drive Yes
Electrical Specifications Voltage: 12 V DC, PoE
Power Consumption: 6.5 ~ 8.5 W
Focal Length mm 2.8 ~ 12
Mount Type Wall, Pole, Corner, Ceiling
Wide Dynamic Range Yes
Picture Elements HxV 3840 x 2160
Network Properties Image Frame Rate: 20 ~ 30 fps
Interface: 1 RJ45 10M/100M self-adaptive Ethernet port
Network Protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
Back Light Compensation Yes
Auto Gain Control Yes
White Balance Yes
Electronic Shutter Range 1/3 ~ 1/100,000s
Compression Type H.264, MJPEG, H.265
Physical Specifications Weight g: 620
Dimensions mm: 127 x 96
Environmental Specifications Protection: IP67
Operating Temperature oC: -30 ~ +60 C (-22 ~ +140 F)
Operating Humidity %: 0 ~ 95
Additional info
  • Up to 8 megapixel high resolution
  • Max. 3840 × 2160@20fps
  • 2.8 mm/4 mm/6 mm/8 mm/12 mm fixed lens, optional
  • H.265, H.265+, H.264+, H.264  •120dB Wide Dynamic Range
  • 3D Digital Noise Reduction
  • DC12V & PoE (802.3af)
  • IR range: up to 30m
