Dahua Wireless PIR-Camera Intrusion Detector
Technical Specification
- Make: Dahua Technology
- Model code: DHI-ARD1731-W2
- PIR Detectors: Yes
- Coverage/ Range m: 12 m
- Pet Tolerance: Yes
Supports IR detection and video review. Maximum resolution 1600 × 1200. One-week cloud cache for videos and images. Quick image transfer. IR illumination range of 12 m at night. Multiple resolution modes available. Detection range: 12 m/86°. Pet immunity function. Auto temperature compensation. 3 adjustable sensitivity levels. Low battery warning alarm. Temperature monitoring. Offers frequency hopping and two-way communication technology, ensuring the stability of communication. Cloud update and automatic recovery from update failure.
Read more| Make | Dahua Technology |
|---|---|
| Manufacturer | Dahua Technology USA Inc. |
| Category | Intruder Alarms>Intruder detectors |
| Model code | DHI-ARD1731-W2 |
| PIR Detectors | Yes |
| Coverage/ Range m | 12 m |
| Pet Tolerance | Yes |
| Power Consumption | 6 W (Max), 0.2 mW (Standby) |
| Temperature Compensation | Yes |
| Mount Type | Wall |
| Vertical Coverage | 2.2 m (7.22 ft) |
| Indoor/Outdoor | Indoor |
| Electrical Specifications | Power Supply: CR123A*3 |
| Physical Specifications | Dimensions mm: 71.0 x 53.2 x 127.6 |
| Environmental Specifications | Operating Temp oC: -10 ~ +55 C (14 ~ 131 F) |
Product description
Introducing the Dahua Technology DHI-ARD1731-W2 Wireless PIR-Camera, a sophisticated solution for enhanced security monitoring. This innovative camera captures high-definition snapshots at a maximum resolution of 1600x1200 using its built-in 2 MP CMOS image sensor. Within approximately 10 seconds, the camera transmits up to six high-resolution images to an alarm hub via RF-HD transmission technology, allowing for swift and accurate visual alarm verification.
Key Features
- High-resolution image capture up to 1600x1200 pixels.
- Two-way communication with frequency hopping for stable signal integrity.
- Temperature monitoring and cloud update capabilities, ensuring the system remains robust and current.
- One-week cloud storage cache for important videos and images.
- PIR motion detection with adjustable sensitivity and pet immunity up to 18 kg.
Ideal Use Cases
The DHI-ARD1731-W2 Wireless PIR-Camera is perfect for safeguarding environments such as villas, apartments, and office buildings. Its discreet design and powerful technology make it an optimal choice for locations requiring a reliable and efficient security solution.
Technical Specifications
- Field of View: 88° horizontal; 68° vertical.
- Illumination Range: 12 metres with infrared light for night vision.
- Operating Temperature: -10°C to +55°C, suitable for varied indoor conditions.
- Wireless Reach: Up to 1,200 metres RF and 300 metres RF-HD in open spaces.
- Power Supply: Three CR123A batteries with a lifespan of up to four years.
