Ajax MotionProtect Outdoor - Wireless Outdoor Motion Detector

Technical Specification

Features:
  • Make: Ajax
  • Model code: MotionProtect Outdoor
  • PIR Detectors: Yes
  • Coverage/ Range m: 3 ~ 15
  • Angle of Detection o: Horizontal — 90°
Read more
Additional info:

Wireless outdoor motion detector with intelligent protection against false alarms. The device operates at low temperatures and is protected against dust and splashes. Accurately detects people LISA turns MotionProtect Outdoor into a formidable barrier for intruders. The digital algorithm accurately identifies the movement of a person while ignoring animals, swaying of trees and plants as well as birds and insects that land on the detector. Prevents intrusions invisible with the naked eye The MotionProtect Outdoor features the maximum possible protection for outdoor detectors. The anti-masking function, which in on around the clock by default, detects installation of barriers, pasting over, application of paint or transparent coating on one or two lenses. The integrated tamper alarms if the dust- and moisture-proof detector body is opened. Grade 3 anti-masking Detects painting and pasting of the detector Protection against unauthorized opening Ready to operate straight out the box MotionProtect Outdoor comes with pre-installed battery, so you do not need to disassemble it. The detector can be connected to the hub by one click in the mobile application. It can be mounted at a height of 0.8 to 1.3 meters on the SmartBracket in just a few minutes. Although the complete battery life is 5 years, it is possible to connect external power supply.

Read more
Make Ajax
Manufacturer Ajax Systems
Model code MotionProtect Outdoor
PIR Detectors Yes
Coverage/ Range m 3 ~ 15
Angle of Detection o Horizontal — 90°
Pet Tolerance Yes
Anti-Masking Yes
Indoor/Outdoor Outdoor
Electrical Specifications Power Supply: 3V
Physical Specifications Dimensions mm: 183 x 70 x 65
Environmental Specifications Operating Temp oC: -25 ~ +60 C (-13 ~ +140 F)
Additional info

Wireless outdoor motion detector with intelligent protection against false alarms. The device operates at low temperatures and is protected against dust and splashes.

Accurately detects people

LISA turns MotionProtect Outdoor into a formidable barrier for intruders. The digital algorithm accurately identifies the movement of a person while ignoring animals, swaying of trees and plants as well as birds and insects that land on the detector.

Prevents intrusions invisible with the naked eye

The MotionProtect Outdoor features the maximum possible protection for outdoor detectors. The anti-masking function, which in on around the clock by default, detects installation of barriers, pasting over, application of paint or transparent coating on one or two lenses. The integrated tamper alarms if the dust- and moisture-proof detector body is opened.

  • Grade 3 anti-masking
  • Detects painting and pasting of the detector
  • Protection against unauthorized opening

Ready to operate straight out the box

MotionProtect Outdoor comes with pre-installed battery, so you do not need to disassemble it. The detector can be connected to the hub by one click in the mobile application. It can be mounted at a height of 0.8 to 1.3 meters on the SmartBracket in just a few minutes. Although the complete battery life is 5 years, it is possible to connect external power supply.

Download PDF version Download PDF version
