ABLOY CYP321T DIN / Europrofile Single Cylinder
Technical Specification
- Make: ABLOY
- Model code: CYP321T
- Door Type: Both
- Weight g: 170
Single cylinder to be used with mortice lock cases and other applications with DIN / Europrofile cylinder dimensions Lock is operated by key from outside Suitable for both outer and inner door use Adjustable length with extension system to match different door thicknesses Adjustable locked position of cam Dust cover
Read more| Make | ABLOY |
|---|---|
| Manufacturer | ASSA ABLOY |
| Category | Access Control>Mechanical digital locks |
| Model code | CYP321T |
| Door Type | Both |
| Physical Specifications | Weight g: 170 |
Product description
ABLOY® CYP321T DIN/Euro Profile Single Cylinder
The ABLOY® CYP321T is a robust single cylinder designed specifically for use with mortice lock cases and applications requiring DIN/Europrofile cylinder dimensions. This innovative lock is crafted to be operated by a key from the outside, making it a versatile solution for both external and internal door security.
Key Features
- Compatible with a wide range of DIN cylinder applications
- Suitable for both outer and inner door installations
- Adjustable length using an extension system to fit various door thicknesses
- Adjustable cam locking position for enhanced security
- Available in multiple plating options, including bright chrome and satin brass
- Equipped with a dust cover to protect the lock mechanism
Technical Specifications
- Weight: 0.17 kg
- Cylinder cross-section adheres to DIN 18252 standard
- Length adjustable in 5 mm increments (31–81 mm) and 10 mm increments (81–131 mm)
Ideal Use Cases
The ABLOY® CYP321T is perfect for a variety of security needs, suitable for enhancing the security of both commercial and residential properties. Its adjustable length and wide range of plating options make it an adaptable choice for architects and building managers seeking reliable, customizable locking solutions.
