ABLOY CY327T DIN Double Cylinder
Technical Specification
- Make: ABLOY
- Model code: CY327T
- Door Type: Both
- Weight g: 230
High durability cylinder against pulling, twisting and sawing Lock is operated outside and inside by a key Suitable for both outer and inner door use Adjustable length with extension system to match different door thicknesses Adjustable locked position of cam
Read more| Make | ABLOY |
|---|---|
| Manufacturer | ASSA ABLOY |
| Category | Access Control>Mechanical digital locks |
| Model code | CY327T |
| Door Type | Both |
| Physical Specifications | Weight g: 230 |
Product description
ABLOY® CY327T DIN Double Cylinder
The ABLOY® CY327T DIN double cylinder sets a benchmark in lock security with its high durability against pulling, twisting, and sawing. Designed for operational efficiency, the lock is operated externally and internally with a key, offering enhanced security for both residential and commercial properties.
Key Features
- Compatible with a wide range of DIN cylinder applications.
- Suitable for use on both outer and inner doors.
- Adjustable length with an extension system to accommodate various door thicknesses.
- Customizable cam locking positions.
- Extensive range of plating options for aesthetic flexibility.
Technical Specifications
- Available Key Systems: ABLOY PROTEC, ABLOY PROTEC², ABLOY NOVEL.
- Plating Options: Bright chrome, Satin chrome, Brushed nickel, Bright brass, Satin brass.
- Outside and Inside Cylinder Length: Both 36mm.
- Adjustable Length: From 36–86mm in 5mm increments and 86–136mm in 10mm increments.
- Weight: 0.23kg.
Ideal Use Cases
The ABLOY® CY327 is perfect for a variety of environments requiring high-security solutions. Its adaptable length and robust construction make it ideal for installation in both interior and exterior doors across corporate offices, educational institutions, and secured residential complexes.
