Vicon VAX-D405R-OSDP Contactless Smartcard Reader
Technical Specification
- Make: Vicon
- Model code: VAX-D405R-OSDP
- Reader Type: Smart Card
- Standalone/ Networkable: Standalone / Networkable
- IP Rating: IP67
Vandal-resistant contactless smartcard reader Reads smartcard credentials, cards/fobs Read range up to 1.5 in. (38 mm) OSDP output interface Single gang box and flat surfaces IP67 rated Powered by 8-14 VDC
Read more| Make | Vicon |
|---|---|
| Manufacturer | Vicon Industries |
| Category | Access Control>Access control readers |
| Model code | VAX-D405R-OSDP |
| Reader Type | Smart Card |
| Standalone/ Networkable | Standalone / Networkable |
| IP Rating | IP67 |
| Mount Type | Surface |
| Read Range mm | 38 |
| LED / Beep | LED / Beep |
| Electrical Specifications |
Voltage: 8 ~ 14 V DC Power Consumption: 135 mA |
| Physical Specifications |
Dimensions mm: 76 x 114 x 25 Weight g: 227 |
| Environmental Specifications | Operating Temp oC: -40 ~ 65 C (-40 ~ 149 F) |
| Protection | IP67 |
Product description
The Vicon VAX-D405R-OSDP is a robust, vandal-resistant contactless smartcard reader designed to meet the needs of environments demanding high durability. Constructed with thick polycarbonate material and epoxy-sealed electronics, this device is perfect for installations such as schools, correctional facilities, and industrial sites. Its advanced design features tamperproof screws and complies with IP67 standards, ensuring superior weather and tamper resistance.
Utilizing the trusted MIFARE® RFID technology, the VAX-D405R-OSDP offers reliable contactless identification with a read range of up to 1.5 inches (38 mm). It supports a variety of smartcard technologies, reading both Card Serial Number (CSN) and sector data. The device interfaces seamlessly with Vicon Access Control systems, supporting both Wiegand and OSDP protocols for flexible integration.
Key Features
- Vandal-resistant construction with thick polycarbonate and epoxy potted electronics
- Supports MIFARE® technology for secure and efficient access control
- Dual interface options: Wiegand and OSDP for versatile connectivity
- IP67-rated for enhanced environmental protection
- Easy installation on single gang boxes or flat surfaces
- Operating temperature range from -40°F to 149°F ensures functionality in extreme conditions
Ideal Use Cases
The VAX-D405R-OSDP is ideal for security applications in environments requiring robust, resilient access control solutions, including educational institutions, correctional facilities, and industrial areas with heavy machinery. Its vandal-resistant design and flexible protocol compatibility make it a prime choice for secure access management.
