TruVision TVP-2104 1/4 Inch True Day/night PTZ Dome Camera

Technical Specification

Features:

Make: TruVision
Model code: TVP-2104
Chip Inch Size: 1/4
Color Type: True Day / Night
Resolution TVL: 700

Additional info:

The TruVision TVP-2104 is a 1/4 inch true day/night dome camera with 700 TVL resolution. The camera is fully programmable, with up to 255 presets, 8 preset tours, and shadow tours for end-user customization and flexibility. A 24-zone privacy mask feature allows the camera to block out sensitive areas such as fitting rooms or restricted areas. This camera has IP66 protection.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	TruVision
Manufacturer	Interlogix
Category	Video Surveillance>Dome cameras
Model code	TVP-2104
Chip Inch Size	1/4
Color Type	True Day / Night
Resolution TVL	700
Sensitivity lux	0.02
Dome Type	PTZ
Indoor/Outdoor	Indoor/Outdoor
Digital (DSP)	Yes
Mount Type	Pendant
Electrical Specifications	Voltage: 24 V AC Power Consumption: 35 W
Presets	255
Electronic Shutter range	1/3 ~ 1/100,000 sec
S/ N (Signal/ Noise) Ratio dB	52
Synchronisation	Internal
Signal Mode	PAL
Video Output	1.0 Vp-p/75 ohm composite
Zoom Ratio	x36
Network Properties	Interface: RS-485
Physical Specifications	Dimensions mm: 266 x 220 Weight g: 3,500
Environmental Specifications	Operating Temp ^oC: -30 ~ +65 C (-22 ~ +149 F) Protection: IP66
Additional info	The TruVision TVP-2104 is a 1/4 inch true day/night dome camera with 700 TVL resolution. The camera is fully programmable, with up to 255 presets, 8 preset tours, and shadow tours for end-user customization and flexibility. A 24-zone privacy mask feature allows the camera to block out sensitive areas such as fitting rooms or restricted areas. This camera has IP66 protection.
