SALTO XS4 S40 narrow body version

SALTO Access Control Platform Now Powered By LEGIC Advant Technology

Product Profile

This product model is not available in this region

SALTO Systems, world leaders in advanced wire free and wireless access control solutions, announces the launch of a new range of products all powered by the latest generation of LEGIC advant contactless smart card technology.

Already partnered with LEGIC Identsystems Ltd, the leading manufacturer of contactless smart card technology for personal identification, the strong relationship between the two companies will allow SALTO to further expand its product platform by offering an increased range of online and offline access control products based on the secure LEGIC advant technology and respond to the globally increasing demand for LEGIC based security solutions.

LEGIC advant is a range of powerful and flexible reader chips for 13.56 MHz contactless smart card technology, used for access control, time & attendance, cashless payment, public transportation and more. Compatible with ISO 14443 A, ISO 15693 and LEGIC prime, its ultra small size and extremely low power consumption makes it a perfect choice for battery-operated applications such as the SALTO access control solution.

“The application of LEGIC advant technology into our range of XS4 electronic escutcheons, wall readers, SALTO GEO cylinder locks and more is extremely important to further strengthen our international business offering” explains Marc Handels, Vice President Global Marketing of SALTO Systems.

“It gives us access to one of the most significant identification technologies on the market and means we can fulfill the growing demand from our worldwide customer base for a LEGIC advant based security solution integrated into SALTO’s class leading access control system.”

Contact manufacturer Contact manufacturer

Make	SALTO
Manufacturer	SALTO Systems
Model code	XS4 S40 narrow body version
Lock Type	Electric Locks
Electric Release Type	Mortice Release
Physical Specifications	Dimensions mm: 282 x 40 x 20
Additional info	Clutch mechanism escutcheon when unlocked handle moves free. ID technologies available: i-Button, DESfire, DESfire EV1, Mifare, Mifare plus, Vicinity, Inside Picopass, Legic, HID iClass, SKIDATA. Available in wireless version for wireless real-time control. Door status detector to monitor intrusions or door left open status (wireless escutceons only). Body and escutcheon made of steel. Handle rotation: 33º. Door thickness compatibility: 30mm to 115mm. Distance from the handle to the cylinder: 105mm. Compatible with Scandinavian modular mortise locks and narrow style mortice lock. Square spindles available 8mm, 8mm split. Electronic privacy function through thumb turn or button on the inside.
Download PDF version Download PDF version

Make

SALTO

Manufacturer

SALTO Systems

Model code

XS4 S40 narrow body version

Lock Type

Electric Locks

Electric Release Type

Mortice Release

Physical Specifications

Dimensions mm: 282 x 40 x 20

Additional info

Clutch mechanism escutcheon when unlocked handle moves free.
ID technologies available: i-Button, DESfire, DESfire EV1, Mifare, Mifare plus, Vicinity, Inside Picopass, Legic, HID iClass, SKIDATA.
Available in wireless version for wireless real-time control.
Door status detector to monitor intrusions or door left open status (wireless escutceons only).
Body and escutcheon made of steel.
Handle rotation: 33º.
Door thickness compatibility: 30mm to 115mm.
Distance from the handle to the cylinder: 105mm.
Compatible with Scandinavian modular mortise locks and narrow style mortice lock.
Square spindles available 8mm, 8mm split.
Electronic privacy function through thumb turn or button on the inside.
