IDIS DC-T4233WRX Full HD IR Bullet Camera

Technical Specification

Features:

Make: IDIS
Model code: DC-T4233WRX
Chip Inch Size: 1/3
Color Type: Color / Monochrome
Resolution: 1080p

Additional info:

Easy installation with DirectIP NVR Full HD (1080p) resolution Motorized Vari-focal lens (f=2.8 - 12mm) micro SD/SDHC/SDXC Two-way audio Alarm in / out IK10 / IP67 supports PoE (IEEE 802.3af Class 3), 12V DC Day and night (ICR) True wide dynamic range (WDR) Low light enhancer IR LED (Distance : 30m / 98.4ft) 3-axis mechanical design for installation Supports ONVIF

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	IDIS
Manufacturer	IDIS
Category	Video Surveillance>IP cameras
Model code	DC-T4233WRX
Chip Inch Size	1/3
Color Type	Color / Monochrome
Resolution	1080p
Digital (DSP)	Yes
Specialist Type	Infrared
Sensitivity Lux	0 ~ 0.0728
Auto Iris	Yes
Direct Drive	Yes
Electrical Specifications	Voltage: 12 V DC, PoE Power Consumption: 14.52 W
Focal Length mm	2.8 ~ 12
Wide Dynamic Range	Yes
Network Properties	Image Frame Rate: 30 ips Interface: RJ45 (10/100BASE-T) Network Protocols: DirectIP™ Mode : DirectIP Protocol,RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/UDP RTSP/TCP, HTTP, HTTPS, FTP, SNTP, SMTP, FEN, mDNS, Upnp
Back Light Compensation	Yes
White Balance	Yes
Electronic Shutter Range	1/30 ~ 1/10,000
S/ N (Signal/ Noise) Ratio dB	> 45
Compression Type	H.265, H.264 (MP) M-JPEG
Physical Specifications	Weight g: 840 Dimensions mm: 77 X 244
Environmental Specifications	Protection: IP67, IK10 Operating Temperature ^oC: -20 ~ +55 C (-4 ~ +131 F) Operating Humidity %: 0 ~ 90
HD	Yes
Additional info	Easy installation with DirectIP NVR Full HD (1080p) resolution Motorized Vari-focal lens (f=2.8 - 12mm) micro SD/SDHC/SDXC Two-way audio Alarm in / out IK10 / IP67 supports PoE (IEEE 802.3af Class 3), 12V DC Day and night (ICR) True wide dynamic range (WDR) Low light enhancer IR LED (Distance : 30m / 98.4ft) 3-axis mechanical design for installation Supports ONVIF
