IDIS DC-D1223W DirectIP Full HD Outdoor Dome Camera

Please note: this is a discontinued product.

Go to Replacement product

Features:

Additional info:

IDIS DC-D1223W is a DirectIP full HD outdoor dome camera.

Contact manufacturer Contact manufacturer

Make	IDIS
Manufacturer	IDIS
Category	Video Surveillance>IP Dome cameras
Model code	DC-D1223W
Chip Inch Size	1/3
Color Type	True Day / Night
Resolution TVL	1920 x 1080
HD	Yes
Sensitivity lux	0.5
Dome Type	PTZ
Indoor/Outdoor	Outdoor
Digital (DSP)	Yes
Electrical Specifications	Voltage: 12 V DC Power Consumption: 4.8 W
Focal length	3 ~ 9 mm
Compression	H.264 (MP), M-JPEG
Back Light Compensation	Yes
Auto Gain Control	Yes
White Balance	Yes
Electronic Shutter range	1/30 ~ 1/8000s
S/ N (Signal/ Noise) Ratio dB	42
Signal Mode	PAL, NTSC
Built-in IR LED	Yes
Video Output	1 terminal block
Network Properties	Interface: RJ-45 (10/100BASE-T) Network Protocols: RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/UDP, RTSP/TCP, HTTP, HTTPS, FTP, SNMP, SMTP, FEN, mDNS, uPNP Image Frame Rate: 30 fps
Physical Specifications	Dimensions mm: 160 x 112 Weight g: 1,180
Environmental Specifications	Operating Temp ^oC: -10 ~ +50 C (14 ~ 122 F) Operating Humidity %: 0 ~ 90 Protection: IP66
Additional info	IDIS DC-D1223W is a DirectIP full HD outdoor dome camera.
Download PDF version Download PDF version
