Honeywell Adds Six New H.264 IP Cameras To The EquIP® IP Range

Product Profile

Honeywell has announced the addition of six IP cameras to its existing equIP® IP product series. The new true day/night cameras are split into two ranges - 1080p and 720p wide dynamic – with each range incorporating three different models; an indoor only mini dome, a vandal resistant mini dome and a box camera.

A core benefit of the new IP cameras is progressive scan video which enables improved detail on moving objects such as faces and car number plates. Furthermore, dual streaming allows each video stream to be configured with an individual resolution whilst Digital Noise Reduction (DNR) results in significant storage savings without sacrificing image quality in low light. The cameras can also be fully integrated with Honeywell’s MAXPRO® NVR SE and XE 2.0 ranges to offer an efficient all Honeywell IP system.

The high resolution of the 1080p cameras allows operators to digitally zoom for superior detail and to cover nearly three times the horizontal area compared with standard fixed analog cameras, potentially reducing the number of cameras required to monitor a fixed space and lowering costs. The 1080p cameras’ superior image detail and ability to highlight small details, such as facial features, means they are suitable for installations that require enhanced detail when zooming in, and the highest possible resolution.

The 720p cameras use wide dynamic technology to improve image visibility even in high contrast environments where objects are hard to identify due to severe backlight or shadows. This allows security personnel to identify subjects in challenging environments such as areas with strong back lighting or abrupt changes in illumination, or when looking from a well lit area into a darker one. The technology delivers video with near-perfect exposure in the harshest of lighting conditions enabling the operator to see recorded events more clearly for use as evidence or to inform decisions.

“Successfully using IP technology to improve the quality, detail and resolution of video recording, particularly in challenging environments, is a constant focus for security manufacturers,” comments Mark Openshaw, Product Manager for Honeywell Security Group EMEA. “Helping installers and end users monitor wider areas and use video footage more effectively is driving the evolution of, and demand for IP solutions.”

For more information regarding these and other Honeywell solutions, please visit

Read more

Technical Specification

Make Honeywell Security
Manufacturer Honeywell
Model code HD3MWIHX
Series EQUIP Series
Chip Inch Size 1/3
Color Type Color / Monochrome
Resolution TVL 1280 × 720
HD Yes
Sensitivity lux 0.1
Dome Type Continuous Rotation
Digital (DSP) Yes
Indoor/Outdoor Indoor
Electrical Specifications Voltage: 24 V AC
Power Consumption: 5 W
Focal length 3.3 ~ 12
Rotation Angleso 360 pan, 180 tilt
Compression H.264, MPEG
Auto Gain Control Yes
White Balance Yes
Electronic Shutter range 1/30 ~ 1/87,000 sec
S/ N (Signal/ Noise) Ratio dB 50
Signal Mode PAL
Video Output 1 Vpp, 75 Ohms
Network Properties Network Protocols: HTTP, TCP, RTSP, RTP, UDP, ARP, DNS, RTCP, FTP, ICMP, DHCP, Bonjour, IGMP, Telnet
Image Frame Rate: 30 fps
Physical Specifications Dimensions mm: 125 x 124
Weight g: 470
Environmental Specifications Operating Temp oC: -10 ~ +50
Operating Humidity %: 0 ~ 85
System Requirments Operating System: Windows XP, Windows 7, Internet Explorer
Additional info The HD3MWIHX is a high-definition, wide dynamic, true day/night indoor fixed minidome network camera engineered to provide extremely crisp images at minimal bandwidth. The HD3MWIHX provides 720p resolution at full frame rate. Progressive scan technology and 2D edge enhancement provide outstanding clarity and definition.
Download PDF version Download PDF version
