Hikvision DS-3E1310P-SI 8 Port Fast Ethernet Smart POE Switch

Technical Specification

This product model is not available in this region

Hikvision DS-3E1310P-SI 8 Port Fast Ethernet Smart POE Switch

Features:

Make: Hikvision
Model code: DS-3E1310P-SI
POE: Yes
Video inputs / ports: 8
Dimensions mm: 266 x 45 x 221

Additional info:

8 × 100 Mbps PoE RJ45 port, 2 × gigabit combo. IEEE 802.3at/af standard for PoE ports. Network topology management, alarm push, network health monitor. 6 KV surge protection for PoE ports. AF/AT camera can reach up to 300 m in extend mode.

Contact manufacturer Contact manufacturer

Make	Hikvision
Manufacturer	Hikvision USA Inc.
Category	Video Surveillance>Switchers & Switches
Model code	DS-3E1310P-SI
POE	Yes
Video inputs / ports	8
Physical Specifications	Dimensions mm: 266 x 45 x 221 Weight g: 2,220
Electrical Specifications	Voltage: 100 ~ 240 V AC Power Consumption: 125 W
Environmental Specifications	Operating Temperature ^oC: -10 ~ 55 C (14 ~ 131 F) Operating Humidity %: 5 ~ 95
Additional info	8 × 100 Mbps PoE RJ45 port, 2 × gigabit combo. IEEE 802.3at/af standard for PoE ports. Network topology management, alarm push, network health monitor. 6 KV surge protection for PoE ports. AF/AT camera can reach up to 300 m in extend mode.
