Hikvision DS-2TD2617-10/QA Thermal & Optical Bi-spectrum Network Bullet Camera

Technical Specification

This product model is not available in this region

Hikvision DS-2TD2617-10/QA Thermal & Optical Bi-spectrum Network Bullet Camera

Features:

Make: Hikvision
Model code: DS-2TD2617-10/QA
Series: HeatPro Series
Chip Inch Size: 1/2.7
Resolution: 160 × 120

Additional info:

160 × 120 resolution, 17 μm, VOx UFPA, NETD < 40 mK (25 °C, F# = 1.1) High accuracy temperature exception alarm, -20 °C to 150 °C (-4 °F to 302 °F), ± 8 °C (±14.4 °F) Image processing technology: linear, histogram, self-adaptive thermal AGC mode, DDE, 3D DNR

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	Hikvision
Manufacturer	Hikvision USA Inc.
Category	Video Surveillance>IP cameras
Model code	DS-2TD2617-10/QA
Series	HeatPro Series
Chip Inch Size	1/2.7
Resolution	160 × 120
Specialist Type	Thermal
Sensitivity Lux	0.0176
Electrical Specifications	Voltage: 12 V DC, PoE Power Consumption: 6 W
Focal Length mm	8 mm
Network Properties	Image Frame Rate: 25/30 fps Interface: 1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface. Network Protocols: IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
Auto Gain Control	Yes
Electronic Shutter Range	1s ~ 1/100,000s
Compression Type	H.265/H.264/MJPEG
Physical Specifications	Dimensions mm: 358.3 x 113.5 x 115.2 Weight g: 1760
Environmental Specifications	Protection: IP66 Operating Temperature ^oC: -40 ~ +65 C (-40 ~ +149 F) Operating Humidity %: <95
Additional info	160 × 120 resolution, 17 μm, VOx UFPA, NETD < 40 mK (25 °C, F# = 1.1) High accuracy temperature exception alarm, -20 °C to 150 °C (-4 °F to 302 °F), ± 8 °C (±14.4 °F) Image processing technology: linear, histogram, self-adaptive thermal AGC mode, DDE, 3D DNR
Download PDF version Download PDF version
