Hikvision DS-2CD2023G2-IU 2 MP WDR Fixed Bullet Network Camera
Technical Specification
- Make: Hikvision
- Model code: DS-2CD2023G2-IU
- Series: Hikvision Pro Series
- Chip Inch Size: 1/2.8
- Color Type: Color / Monochrome
High quality imaging with 2 MP resolution Clear imaging against strong backlight due to 120 dB WDR technology Efficient H.265+ compression technology -U: Built-in microphone for real-time audio security Water and dust resistant (IP67) Focus on human and vehicle targets classification based on deep learning
Read moreMake | Hikvision |
---|---|
Manufacturer | Hikvision USA Inc. |
Category | Video Surveillance>IP cameras |
Model code | DS-2CD2023G2-IU |
Series | Hikvision Pro Series |
Chip Inch Size | 1/2.8 |
Color Type | Color / Monochrome |
Resolution | 2MP |
Digital (DSP) | Yes |
Specialist Type | Network |
Sensitivity Lux | 0.005 ~ 0 |
Auto Iris | Yes |
Direct Drive | Yes |
Electrical Specifications |
Voltage: 12 V DC, POE Power Consumption: 6 W |
Motion Activated | Yes |
High Speed | Yes |
Focal Length mm | 2.8 ~ 4 |
Wide Dynamic Range | Yes |
Picture Elements HxV | 1920 × 1080 |
Network Properties |
Image Frame Rate: 25 ~ 30 fps Interface: 1 RJ45 10M/100M Network Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE |
Back Light Compensation | Yes |
Auto Gain Control | Yes |
White Balance | Yes |
Electronic Shutter Range | 1/3 s to 1/100,000 s |
Compression Type | H.265/H.264/H.264+/H.265+/MJPEG |
Physical Specifications |
Weight g: 490 Dimensions mm: 70 x 162 |
Environmental Specifications |
Protection: IP67 Operating Temperature oC: -30 ~ 60 C (-22 ~ 140 F) Operating Humidity %: 0 ~ 90 |
System Requirements | Web Browser: IE 10, IE 11, Chrome 57.0+, Firefox 52.0+, Chrome 57.0+, Firefox 52.0+ |
HD | Yes |
Additional info |
|
Download PDF version Download PDF version |
