Hanwha Vision PNV-A7082RZ 4MP AI Outdoor Vandal Dome Camera
Technical Specification
- Make: Hanwha Vision
- Model code: PNV-A7082RZ
- Chip Inch Size: 1/1.8
- Color Type: Color / Monochrome
- Resolution TVL: 4MP
Business intelligence based on AI engine : People/Vehicle/Crowd counting, Queue management, Heatmap Support BestShot and full attributes Support Dynamic Privacy Masking AI-based Image enhancement extremeWDR, WiseNRⅡ(Based on AI engine), WiseStream(Based on AI engine) Support Wisepower(Power monitoring) Device certificate(Hanwha Vision Root CA), Secure storage(Secure element with FIPS 140-3 level3/CC EAL6+ certified), SBOM 2 SD slots edge storage
Read more| Make | Hanwha Vision |
|---|---|
| Manufacturer | Hanwha Vision America |
| Category | Video Surveillance>IP Dome cameras |
| Model code | PNV-A7082RZ |
| Chip Inch Size | 1/1.8 |
| Color Type | Color / Monochrome |
| Resolution TVL | 4MP |
| Megapixel | Yes |
| Sensitivity lux | Color: 0.03Lux ; BW: 0.003Lux |
| Indoor/Outdoor | Outdoor |
| Focal length | 4.6 ~ 9.35 mm |
| Compression | H.265/H.264: Main/Baseline/High, MJPEG |
| Back Light Compensation | Yes |
| Auto Gain Control | Yes |
| White Balance | Yes |
| Electronic Shutter range | 2~1/30,000sec |
| Network Properties |
Interface: Metal shielded RJ-45(10/100/1000BASE-T) Network Protocols: IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SFTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, CDP, SRTP(TCP, UDP Unicast), MQTT, Syslog |
| Electrical Specifications | Power Consumption: Max. 15.0W, typical 9.0W |
| Physical Specifications |
Dimensions mm: ø180 x 135 Weight g: 2100 |
| Environmental Specifications |
Operating Temp oC: -50 ~ +55 C (-58 ~ +131 F) Operating Humidity %: 0 ~ 100 Protection: IP66/IP67/IP6K9K, IK11 |
Product description
PNV-A7082RZ: 4MP AI Outdoor Vandal Dome Camera
The Hanwha Vision PNV-A7082RZ is a highly advanced 4MP AI outdoor vandal dome camera, designed for challenging security environments. It features a 1/1.8" sensor, providing exceptional image resolution, and is equipped with a motorised varifocal lens ranging from 4.6 to 9.35mm for flexible installation.
Key Features
- Delivers up to 4MP resolution
- Motorised varifocal lens: 4.6~9.35mm (2.0x zoom)
- Long-range WiseIR with coverage up to 30m
- Robust AI engine facilitating object detection & business intelligence
- Dynamic image enhancement including AI-based extremeWDR and WiseNRⅡ
- Comprehensive security: device certificate with FIPS 140-3 level 3 compliance and secure storage
- Dual SD card slots for edge storage
Ideal Use Cases
The PNV-A7082RZ is built for environments demanding high durability and precision, such as city surveillance, large venues, and industrial sites. It effectively handles a variety of challenging lighting conditions, making it ideal for 24/7 monitoring.
Advanced Analytics & Intelligence
- AI-driven analytics for diverse identification tasks including people, face, and vehicle detection
- Business intelligence capabilities include crowd counting and queue management
- Supports the prevention of potential health risks through social distancing detection
- Enhanced operational control and security through smart notifications and alarm triggers
With its rugged construction complying with IP66/IP67 standards, this camera ensures resilience in harsh weather, making it a powerful asset in safeguarding any high-security area.
