Dedicated Micros Launches Intelligent Managed Storage Unit (MSU)

Product Profile

Dedicated Micros - part of AD Group - has announced the launch of a new Managed Storage Unit (MSU) to deliver high-capacity, external storage, with advanced features built-in such as power management and environmental control of individual disks.

The Managed Storage Unit (MSU) has been designed to offer increased video storage - up to 5TB per unit - for compatible Dedicated Micros' NetVu Connected Digital Video Recorders (DVRs) and Network Digital Video Recorders (NDVRs) fitted with external SATA connectors, including the DV-IP RT, HighVu Excel, SD Range, DV-IP HD and DV-IP Express.

Using a combination of continuous monitoring and environmental control, the MSU is able to ensure that disks are individually monitored and cooled to optimize operating conditions. Crucially, an intelligent power management capability ensures that disks are only in operation when access is actually required.

Said Pauline Norstrom, Director of Worldwide Marketing at Dedicated Micros: "With the new MSU we have taken a considered, pro-active, approach to storage management. As a result we expect disk life with the MSU to be greatly extended compared to more conventional options, so ensuring that system up-time is maximised and maintenance costs kept to an absolute minimum."

Additionally, the MSU features automatic detection from compatible DVRs which greatly simplifies the installation process, whilst health reporting and field serviceable drives ensure that maintenance can be planned and undertaken with the minimum of disruption.

Read more

Technical Specification

Make Dedicated Micros
Manufacturer Dedicated Micros
Model code MSUA5T0
Physical Specifications Dimensions mm: 89 x 440 x 537
Weight g: 1,665
Electrical Specifications Power Consumption: 200 W
Voltage: 120 / 240 V AC
Environmental Specifications Operating Temperature oC: 5 ~ 45
Operating Humidity %: 5 ~ 85
Additional info

5.0 TB storage (other models available with 1.25 TB, 2.5 TB and 3.75 TB). SATA connection. Intelligent power management. Compatible with next generation DVRs from Dedicated Micros including the DV-IP Server, DV-IP HD, DV-IP Express, DV-IP RT, SD Range and HighVu Excel installation. 2U rack mount chassis or desktop.  Service drawer allowing access to all serviceable components from the front panel.

Download PDF version Download PDF version
