Dedicated Micros DM/ICEVC-DNU39 Ice Range Ceiling Mount 1/3” Day / Night 540 TVL 0.15 Lux Varifocal 3-9mm

Technical Specification

Features:
  • Make: Dedicated Micros
  • Model code: DM/ICEVC-DNU39
  • Series: ICE Range
  • Chip Inch Size: 1/3
  • Color Type: Color / Monochrome
Read more
Additional info:

Direct drive (DD) auto iris lens.

Read more
Make Dedicated Micros
Manufacturer Dedicated Micros
Model code DM/ICEVC-DNU39
Series ICE Range
Chip Inch Size 1/3
Color Type Color / Monochrome
Resolution TVL 540
Sensitivity lux 0.15
Dome Type Variable Focus
Indoor/Outdoor Indoor/Outdoor
Digital (DSP) Yes
Mount Type Ceiling
Electrical Specifications Voltage: 12 V DC / 24 V AC
Power Consumption: 2 W
Focal length 3.6 ~ 9
Electronic Shutter range 1/50 ~ 1/100,000
S/ N (Signal/ Noise) Ratio dB 50
Synchronisation Internal, Line-lock
Video Output 1.0 Vp-p, 75 Ohms
Physical Specifications Dimensions mm: 122 x 160
Weight g: 1,000
Environmental Specifications Operating Temp oC: -10 ~ +50
Operating Humidity %: 20 ~ 80
Additional info Direct drive (DD) auto iris lens.
