Dahua Technology XVR5108HS-I3 8 Channel Penta-brid 5M-N/1080p Compact 1U 1HDD WizSense DVR
Technical Specification
Features:
- Make: Dahua Technology
- Model code: XVR5108HS-I3
- Series: WizSense Series
- Channels: 8
- Hybrid IP inputs: 12
Additional info:
H.265+/H.265 dual-stream video compression Supports Full-channel AI-Coding Supports HDCVI/AHD/TVI/CVBS/IP video inputs Max 12 channels IP camera inputs, each channel up to 6MP; Max 64 Mbps incoming bandwidth Up to 1 channel video stream ( analog channel ) Perimeter Protection Up to 8 channels video stream ( analog channel ) SMD Plus
Read more| Make | Dahua Technology |
|---|---|
| Manufacturer | Dahua Technology USA Inc. |
| Category | Video Surveillance>Digital video recorders (DVRs) |
| Model code | XVR5108HS-I3 |
| Series | WizSense Series |
| Channels | 8 |
| Hybrid IP inputs | 12 |
| Inbuilt Multiplexer | Yes |
| Storage Capacity GB | 10TB |
| Compression Type | AI Coding, H.265+, H.265, H.264+, H.264 |
| Resolution | 6MP |
| Signal Mode | PAL / NTSC |
| External Storage | USB |
| Recording System | HDD |
| Audio Recording and Properties | G.711A, G.711U, PCM |
| Type of Multiplexer Functions | Recording, Playback |
| IP Storage rate (fps) | 10 ~ 30 |
| Network Type | HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, SNMP, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search ( |
| Physical Specifications |
Dimensions mm: 260 x 238 x 48 Weight kg: 1.19 |
| Electrical Specifications |
Voltage: 12 V DC Power Consumption: 7 W |
| Environmental Specifications |
Operating Temp oC: -10 ~ +55 C (14 ~ 131F) Operating Humidity %: 0 ~ 90 |
| Additional info |
|
