Dahua DH-HAC-T1A51-U 5MP IR HDCVI Fixed-focal Eyeball Camera
Technical Specification
Features:
- Make: Dahua Technology
- Model code: DH-HAC-T1A51-U
- Series: Cooper Series
- Color Type: Color / Monochrome
- Resolution TVL: 5 MP
Additional info:
Max 25 fps@5MP (16:9 video output). Smart IR Illumination. 25 m illumination distance. Quick-to-install eyeball saves installation time. 2.8 mm fixed lens (3.6 mm optional). CVI/CVBS/AHD/TVI switchable
Read more| Make | Dahua Technology |
|---|---|
| Manufacturer | Dahua Technology USA Inc. |
| Category | Video Surveillance>Surveillance cameras |
| Model code | DH-HAC-T1A51-U |
| Series | Cooper Series |
| Color Type | Color / Monochrome |
| Resolution TVL | 5 MP |
| Sensitivity lux | 0.02 lux@F2.0 (Color, 30 IRE) ; 0.002 lux@F2.0 (B/W, 30 IRE) ; 0 lux (Illuminator on) |
| Electrical Specifications |
Voltage: 12 V DC Power Consumption: Max 2.7 W |
| Motion Activated | Yes |
| Focal Length mm | 2.8 mm; 3.6 mm |
| Mount Type | Wall, Ceiling |
| Wide Dynamic Range | Yes |
| Back Light Compensation | Yes |
| Auto Gain Control | Yes |
| White Balance | Yes |
| Electronic Shutter range | PAL: 1/25 s–1/100,000 s; NTSC: 1/30 s–1/100,000 s |
| S/ N (Signal/ Noise) Ratio dB | >65 dB |
| Signal Mode | PAL, NTSC |
| Video Output | CVI/TVI/AHD/CVBS by one BNC port |
| Physical Specifications |
Dimension mm: Φ85.0 x 77.1 Weight g: 110 |
| Environmental Specifications |
Operating Temperature oC: -40 ~ +55 C (-40 ~ +131 F) Operating Humidity %: < 95 |
| Additional info |
|
