AXIS 262 Network Video Recorder
Product Profile
AXIS 262+ NVR is a network-based video recorder, compatible with all Axis JPEG products with firmware 3.15 or higher.
It contains a 250 GB HDD for storing e.g. 13 days of VGA @ 1fps, 8 channels (20kbyte) of high quality video with no quality degradation compared to the original image from the camera or video server. It has a recording speed of 120 frames per second at VGA and has a 250 GB hard disk with Anti-Vibration. It comes with feature like support for scheduled, manual and triggered recordings. Take advantage of your network by implementing an Axis surveillance system.
AXIS 262+ NVR offers together with their cameras and video servers the customer a complete surveillance solution where one manufacturer guarantees all functions and compatibility.
Key features:
Read more
It contains a 250 GB HDD for storing e.g. 13 days of VGA @ 1fps, 8 channels (20kbyte) of high quality video with no quality degradation compared to the original image from the camera or video server. It has a recording speed of 120 frames per second at VGA and has a 250 GB hard disk with Anti-Vibration. It comes with feature like support for scheduled, manual and triggered recordings. Take advantage of your network by implementing an Axis surveillance system.
AXIS 262+ NVR offers together with their cameras and video servers the customer a complete surveillance solution where one manufacturer guarantees all functions and compatibility.
Key features:
- Records from up to eight network video cameras with Megapixel resolution
- Simultaneous recording, live viewing and playback of recorded images
- Easy to install, use and manage
- Records up to 120 frames per second at VGA or 4CIF
- Remote access to recorded material as well as to live cameras
- 250 GB hard disk with Anti-Vibration
Technical Specification
Make | Axis Communications |
---|---|
Manufacturer | Axis Communications |
Category | Video Surveillance>Digital video recorders (DVRs) |
Model code | AXIS 262+ Network Video Recorder |
Channels | 8 |
Recording Mode | Real Time / Timelapse / Event |
Inbuilt Multiplexer | Yes |
Monitor Outputs | 1 |
Multiplexer Type | Duplex |
Storage Capacity GB | 250 |
Image per second (IPS) | 240 over all cameras |
Compression Type | M-JPEG |
Resolution | 4CIF |
Signal Mode | PAL, NTSC |
Recording System | HDD |
Mount type | 8 in, 1 out |
Network Type | Ethernet 10BaseT/100BaseTX, RJ-45 |
IP Ready | PTZ |
Physical Specifications |
Dimensions mm: 72 x 310 x 290 Weight kg: 5 |
Electrical Specifications |
Voltage: 12 V DC Power Consumption: 50 W |
Environmental Specifications |
Operating Temp oC: 5 ~ 40 Operating Humidity %: 20 ~ 80 |
Additional info | The Axis 262+ NVR is a complete recording solution ideal for storing video with up to mega pixel resolution with no quality degradation. Connecting directly to network, the open application protocol interface and sophisticated networking functions based on open industry standards greatly simplify systems integration. |
