Arecont Vision AV10005DN 10 Megapixel IP Camera With H.264 Compression

Technical Specification

Features:
  • Make: Arecont Vision
  • Model code: AV10005DN
  • Series: IPELA ENGINE EX C Series
  • Chip Inch Size: 1/2
  • Color Type: Color / Monochrome
Read more
Additional info:

The AV10005 series network camera is part of Arecont Vision’s full line of H.264 megapixel cameras. This fully compliant implementation of H.264 (MPEG 4, Part 10) is capable of sustaining over 80 billion operations per second and maintaining full motion progressive scan 3648 x 2752 video at 5fps. Part of the MegaVideo line of cameras, it offers bandwidth and storage efficiency of 10X greater on average over traditional megapixel counterparts.

Read more
Make Arecont Vision
Manufacturer Arecont Vision
Model code AV10005DN
Series IPELA ENGINE EX C Series
Chip Inch Size 1/2
Color Type Color / Monochrome
Resolution 3648 x 2752
Digital (DSP) Yes
Specialist Type Megapixel
Sensitivity Lux 0.0
Lens Mount C/CS
Electrical Specifications Voltage: 12 ~ 48 VDC, 24 VAC, PoE
Power Consumption: 5 W
Motion Activated Yes
Network Properties Image Frame Rate: 60 fps
Interface: 100Base-T Ethernet
Network Protocols: TFTP, HTTP, RTSP, RTP/TCP, RTP/UDP
Back Light Compensation Yes
Auto Gain Control Yes
S/ N (Signal/ Noise) Ratio dB 40
Zoom Yes
Compression Type H.264, M-JPEG
Physical Specifications Weight g: 243
Dimensions mm: 76 x 57 x 64
Environmental Specifications Operating Temperature oC: 0 ~ 50
Operating Humidity %: 0 ~ 90
Additional info The AV10005 series network camera is part of Arecont Vision’s full line of H.264 megapixel cameras. This fully compliant implementation of H.264 (MPEG 4, Part 10) is capable of sustaining over 80 billion operations per second and maintaining full motion progressive scan 3648 x 2752 video at 5fps. Part of the MegaVideo line of cameras, it offers bandwidth and storage efficiency of 10X greater on average over traditional megapixel counterparts.
