AirLive MD-720 Wide Angle Mini Dome IP Camera

Technical Specification

Features:

Make: AirLive
Model code: MD-720
Chip Inch Size: 1/4
Color Type: Color
Resolution TVL: 1280 x 800

Additional info:

AirLive MD-720 IP camera is the latest indoor mini dome camera from AirLive. It combines 720P HD video, wide angle lens, power over Ethernet, and excellent image quality into one compact size. It is only about the half size of a standard dome camera, which makes it suitable for elevators, office, shops, home, and public areas, and even public transportation.

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	AirLive
Manufacturer	AirLive (Ovislink)
Category	Video Surveillance>IP Dome cameras
Model code	MD-720
Chip Inch Size	1/4
Color Type	Color
Resolution TVL	1280 x 800
HD	Yes
Megapixel	Yes
Sensitivity lux	0.2
Indoor/Outdoor	Indoor
Mount Type	Ceiling
Compression	H.264 / MPEG4 / MJPEG
Zoom Ratio	x10
Network Properties	Network Protocols: TCP/ IP, DHCP, PPPoE, ARP, ICMP, FTP,SMTP, DNS, NTP, UPnP, Bonjour, RTSP, RTP, HTTP, TCP,UDP,3GPP/ ISMA RTSP Image Frame Rate: 30 fps
Electrical Specifications	Power Consumption: 8W
Physical Specifications	Dimensions mm: 61 x 99 x 99
Environmental Specifications	Operating Temp ^oC: 0 ~ 50 Operating Humidity %: 20 ~ 85
System Requirements	Web Browser: IE 6.0 or later, Firefox 2.0 or later, Safari
Additional info	AirLive MD-720 IP camera is the latest indoor mini dome camera from AirLive. It combines 720P HD video, wide angle lens, power over Ethernet, and excellent image quality into one compact size. It is only about the half size of a standard dome camera, which makes it suitable for elevators, office, shops, home, and public areas, and even public transportation.
