Visionhitech VDA110CSHR-VFA12DN 540 TVL true day/night dome camera
Technical Specification
Features:
- Make: Visionhitech
- Model code: VDA110CSHR-VFA12DN
- Chip Inch Size: 1/3
- Color Type: True Day / Night
- Resolution TVL: 540 TVL
| Make | Visionhitech |
|---|---|
| Manufacturer | Visionhitech Co., Ltd |
| Category | Video Surveillance>Dome cameras |
| Model code | VDA110CSHR-VFA12DN |
| Chip Inch Size | 1/3 |
| Color Type | True Day / Night |
| Resolution TVL | 540 TVL |
| Sensitivity lux | 0.2 |
| Electrical Specifications |
Voltage: 12 V DC Power Consumption: 90mA |
| Focal length | 3.3 ~ 12 mm |
| Back Light Compensation | Yes |
| Auto Gain Control | Yes |
| White Balance | Yes |
| Electronic Shutter range | 1/60 ~ 1/120,000 s |
| S/ N (Signal/ Noise) Ratio dB | >50 |
| Synchronisation | Internal |
| Signal Mode | NTSC/PAL |
| Video Output | 1.0Vp-p Composite. 75 Ohms |
| Zoom Ratio | x2.5 |
| Physical Specifications |
Dimensions mm: 122 x 164 Weight g: 1,200 |
| Environmental Specifications |
Operating Temp oC: -10 ~ +50 Operating Humidity %: < 90 |
