ABLOY Security access systems

ABLOY PE920 is a passive door package for mechanical solid doors.

ABLOY CY424T is a single ANSI cylinder.

The lock can be opened from outside by a key and inside by a handle The lock deadlocks automatically when the door closes Fire resistant

Lock case for profile doors Has a lever handle function Fire resistance

Lock case with an automatically deadlocking latchbolt The lock has no lever handle operation The bolt is opened with either a key or a thumbturn Fire resistance

ABLOY 9121 is a mechanical lock with long front plate.

ABLOY PE900 is a mechanical lock package for passive leaf doors.

Security lock case (comparable with security grade 5 according to EN 12209) for narrow profile doors Operates with key from either side with a double cylinder or from outside with a cylinder and inside with a thumbturn or from one side only with a single cylinder The key can only be removed when the hardened hookbolt is fully locked or retracted Microswitch version The switch changes its status when the hookbolt moves from unlocked to locked position

Always latches when closing the door For Scandinavian range cylinders The lock is opened with a key or a thumbturn The lock can be used with an electric striker plate The cylinder and thumbturn which is used more is recommended to be installed higher up The locks can be equipped with a thumbturn, a one sided cylinder and/or a double sided cylinder The lower cylinder is installed upside down due to the construction of the lock

The lock can be opened either with a key (outside and inside) or by using an emergency thumbturn Automatic deadlocking when the door is closed

ABLOY PE910 is a mechanical lock package for passive leaf doors.

Mechanical lock with night- and day functions The lock can be opened from outside by a key and inside by a handle The lock deadlocks automatically when the door closes

Function is determined by sliding snib on forend When the snib is in its up position, the lock will deadlock when the door is closed and can only be opened by a key or by the thumbturn When the snib is in its middle position, the lock will latch normally, but can be opened by the handles as well as the key and the thumbturn When the snib is in its down position, the latchbolt is retained inside the lock case Microswitch version The switch changes its status when the bolt is fully extended

Automatic deadlocking when the door is closed The lock is opened with a key or a thumbturn The cylinder and thumbturn which is used more is recommended to be installed higher up The lock can be fitted with a thumbturn and/or a one sided or a double sided cylinder The lower cylinder is installed upside down due to the construction of the lock Fire resistance: suitable for fire doors

The lock case setting snib is locked to the middle option The lock opens by cylinder- or thumbturn action If necessary, a handle can be installed The lock does not have a deadlock mechanism Installing handles on both sides of the door is mandatory if used as a fire door The lock can be used with an electric striker plate Microswitch version The switch will change its status when the bolt is fully extended Fire resistance

The lock can be opened either with a key (outside and inside) or by using an emergency thumbturn (sliding snib in UP position) Latchbolt can be retained inside the lock case (sliding snib in DOWN position) Sliding snib is released only when turning the key

Function is determined by sliding snib on forend When the snib is in its up position, the lock will deadlock when the door is closed and can only be opened by a key or by the thumbturn When the snib is in its middle position, the lock will latch normally, but can be opened by the handles as well as the key and the thumbturn When the snib is in its down position, the latchbolt is retained inside the lock case

Security lock (SFS 7020 grade 3 and comparable with security grade 5 according to EN 12209) Compatible with one-way rotating cylinders Operates with key from either side with a double cylinder or from outside with a cylinder and inside with a special thumbturn or from one side only with a single cylinder The key can only be removed when the hardened hookbolt is fully locked or retracted Microswitch version The switch changes its status when the hookbolt moves from unlocked to locked position

The door is opened from outside with a door pull The lock case fulfills the requirements of the European standard for exit products SFS-EN179 and SFS-EN1125 and the requirements of the lock case standard SFS-EN12209 The lock is always opened from the inside by a lever handle or panic bar Deadlocking is controlled by a snib in the front plate Using of the snib is normally blocked The snib is released by turning the key When the snib is in its up position, the lock will deadlock when the door closes and can only be opened by a key from the outside or by a lever handle, push pad, or panic bar from the inside When the snib is in its down position, the latchbolt is retained inside the lock case

The door is opened from outside with a door pull The lock case fulfills the requirements of the European standard for exit products SFS-EN179 and SFS-EN1125 and the requirements of the lock case standard SFS-EN12209 The lock is always opened from the inside by a lever handle or panic bar The latchbolt protrudes 14 mm Deadlocking is controlled by a snib in the front plate Using of the snib is normally blocked The snib is released by turning the key When the snib is in its up position, the lock will deadlock when the door closes and can only be opened by a key from the outside or by a lever handle, push pad, or panic bar from the inside When the snib is in its down position, the lock can be also be opened by the exterior handle Fire resistance

Lock case with an automatically deadlocking latchbolt The lock must always be equipped with handles, as the latchbolt is only retracted with the handles The deadlocking is controlled by a snib in the forend When the snib is in deadlocking mode, the door is opened by turning the outside key 180° or the inside thumbturn 90° The handles are then activated, and the latchbolt can be retracted When the snib is in its up position, the lever handles are activated by the key or the thumbturn When the snib is in its down position, the handles work normally The lock case is fitted with a feature to prevent the unauthorized use of the snib The snib is locked to the deadlocking mode by turning a set screw, located below the snib, about two turns anticlockwise by a hexagonal key, until the screw stops and is opened by turning the screw clockwise Fire resistance

The lock must always be equipped with handles on both sides of the door, as the lock is only operated by the handles The deadlocking is controlled by a snib in the forend When the snib is in deadlocking mode, the door is opened by turning the outside key 180° or the inside thumbturn 90° The handles are then activated, and the latchbolt can be retracted When the snib is in its up position, the lever handles are activated by the key or the thumbturn When the snib is in its down position, the handles work normally The lock case is fitted with a feature to prevent unauthorized use of the snib The snib is locked to the deadlocking mode by turning a set screw, located below the snib, about two turns anticlockwise by a hexagonal key, until the screw stops and is opened by turning the screw clockwise Fire resistance

The lock is opened by a key or a thumbturn The non-deadlocking latchbolt protrudes 14 mm The lock can also be used with electric striker plates Fire resistance

ABLOY 9120 is a mechanical lock with long front plate.

Security lock (SFS 7020 grade 3 and comparable with security grade 5 according to EN 12209) for solid doors The lock case works with the 4690, 4691, LP711, LP714, LP721, and LP731 striker plates

ABLOY EA452 is a control unit.

The door is opened from outside with a door pull The lock case fulfills the requirements of the European standard for exit products SFS-EN179 and SFS-EN1125 and the requirements of the lock case standard SFS-EN12209 The lock is always opened from the inside by a lever handle or panic bar The lock is deadlocked always when the door is closed The latchbolt protrudes 14 mm

Security mortice lock case (security grade 5 according to EN 12209) with hardened deadbolt and drilling protection The deadbolt has a 20 mm bolt throw The deadbolt is locked and retracted by turning the key or thumbturn 360° The key can only be removed when the deadbolt is fully locked or retracted
