ABLOY Security access systems

Cylinder lock case for emergency doors The latchbolt extends 21 mm The lock case is equipped with a double cylinder and an exit thumbturn Fire resistance

Lock case with an automatically deadlocking latchbolt The lock has no lever handle operation The bolt is opened with either a key or a thumbturn Fire resistance

The bolt can be locked inside the lock case The deadlocking can be controlled by a sliding snib on the forend of the lock case When the snib is in its up position, the lock deadlocks and can only be opened by a key or by the thumbturn When the snib is in its down position, the bolt is locked inside the lock case

The BEAT Key Deposit enables keyless access to properties with a smartphone via a Bluetooth Low Energy (BLE) connection. The BEAT Key Deposit is designed to perform in harsh conditions with its IP66/68 and IK10 certifications. Property managers can conveniently grant different user groups access to properties via the users’ mobile phones, without the need for unnecessary key logistics and access control.

ABLOY EA460 is a control unit for the EL648 lockcase.

ABLOY EA280 is a lead cover to cover cables as they travel from the door to the frame.

ABLOY PE911 is a mechanical lock package for passive leaf doors.

The lock can be opened either with a key (outside and inside) or by using an emergency thumbturn Automatic deadlocking when the door is closed Microswitch version The switch changes it’s status when the latchbolt is fully extended

The door is opened from outside with a door pull The lock case fulfills the requirements of the European standard for exit products SFS-EN179 and SFS-EN1125 and the requirements of the lock case standard SFS-EN12209 The lock is always opened from the inside by a lever handle, push pad or panic bar The latchbolt protrudes 14 mm Deadlocking is controlled by a snib in the front plate Using of the snib is normally blocked. The snib is released by turning the key When the snib is in its up position, the lock will deadlock when the door closes and can only be opened by a key from the outside or by a lever handle or panic bar from the inside When the snib is in its down position, the latchbolt is retained inside the lock case Microswitch version The switch changes the status when latchbolt is deadlocked

Security mortice lock case (security grade 5 according to EN 12209) with hardened deadbolt and drilling protection The deadbolt has a 20 mm bolt throw The deadbolt is locked and retracted by turning the key or thumbturn 360° The key can only be removed when the deadbolt is fully locked or retracted Microswitch version The switch changes it's status when deadbolt is fully extended (Deadlocked)

The door is opened from outside with a lever handle The lock case fulfills the requirements of the European standard for exit products SFS-EN179 and SFS-EN1125 The lock is always opened from the inside by a lever handle, push pad or panic bar The latchbolt protrudes 14 mm Deadlocking is controlled by a snib in the front plate Using of the snib is normally blocked. The snib is released by turning the key When the snib is in its up position, the lock will deadlock when the door closes and can only be opened by a key from the outside or by a lever handle or panic bar from the inside When the snib is in its down position, the lock will latch normally and the lock can be opened also by the exterior handle

Lock case for Scandinavian range cylinders The deadbolt is locked and retracted by turning the key or thumbturn 90° A further 5° turn will retract the latchbolt as well The latchbolt is retracted also by the lever handles

The door is opened from outside with a door pull The lock case fulfills the requirements of the European standard for exit products SFS-EN179 and SFS-EN1125 and the requirements of the lock case standard SFS-EN12209 The lock is always opened from the inside by a lever handle or panic bar The latchbolt protrudes 14 mm Deadlocking is controlled by a snib in the front plate Using of the snib is normally blocked The snib is released by turning the key When the snib is in its up position, the lock will deadlock when the door closes and can only be opened by a key from the outside or by a lever handle, push pad, or panic bar from the inside When the snib is in its down position, the latchbolt is retained inside the lock case

The deadlocking is controlled by a snib in the forend When the snib is in its up position, the door will deadlock when closing and can only be opened with a key or the thumbturn When the snib is in its down position, the door can also be opened with the handles Fire resistance

Deadlocking can be controlled by a sliding snib on the forend of the lock case When the snib is in its up position, the door will deadlock when closed and can only be opened by a key or by the thumbturn When the snib is in its down position, the bolt is locked inside the lock case

Doesn't support handles The lock can only be opened by a key or by the thumbturn The bolt cannot be deadlocked Can be used with electric striker plates Fire resistance

The keyless BEAT Bluetooth controller makes electric locks or other electric door locking devices work with the BEAT mobile application. With the controller you can conceal your locking mechanisms and control access with mobile app.

The door is opened from outside with a door pull The lock case fulfills the requirements of the European standard for exit products SFS-EN179 and SFS-EN1125 and the requirements of the lock case standard SFS-EN12209 The lock is always opened from the inside by a lever handle or panic bar The lock is deadlocked always when the door is closed The latchbolt protrudes 14 mm Microswitch version The switch changes the status when latchbolt is deadlocked

For scandinavian type of usage - cylinder works in both directions Latch protrusion is 21mm

Deadlocking can be controlled by a sliding snib on the forend of the lock case When the snib is in its up position, the door will deadlock when closed and can only be opened by a key or by the thumbturn When the snib is in its down position, the door can be opened by the handles as well Fire resistance

Mechanical lock with night- and day functions The lock can be opened from outside by a key and inside by a handle The lock deadlocks automatically when the door closes Snib can be set for secure and daytime positions Daytime snib position enables handle usage Secure snib position keeps outside handle freewheeling

The deadlocking is controlled by the snib in the forend When the snib is in the up position, the door will deadlock when closed It can then be opened by a key or by the thumbturn When the snib is in the down position, the hookbolt is retained inside the lock case

ABLOY EA421 is a control unit.

ABLOY EA281 is a lead cover to cover cables as they travel from the door to the frame.

ABLOY EA430 is a Hi-O control unit.

ABLOY BEAT – our growing, keyless product range for critical infrastructure protection. These mobile and smart innovations are a step towards a new era of fully connected, digital access control. Powered by Seos® credential technology, the BEAT solutions provide exceptional security and privacy protection specifically designed for critical infrastructure. They are always in sync with your security situation and add efficiency to your operations.

ABLOY EA420 is a control unit for EL420 and EL520 lockcases.

ABLOY EA700 is a 12 VDC, 4.5A transformer for electric locks.
