Always latches when closing the door For Scandinavian range cylinders The lock is opened with a key or a thumbturn The lock can be used with an electric striker plate The cylinder and thumbturn which is used more is recommended to be installed higher up The locks can be equipped with a thumbturn, a one sided cylinder and/or a double sided cylinder The lower cylinder is installed upside down due to the construction of the lock

The lock can be opened either with a key (outside and inside) or by using an emergency thumbturn Automatic deadlocking when the door is closed

The door is opened from outside with a door pull The lock case fulfills the requirements of the European standard for exit products SFS-EN179 and SFS-EN1125 and the requirements of the lock case standard SFS-EN12209 The lock is always opened from the inside by a lever handle, push pad or panic bar The latchbolt protrudes 14 mm Deadlocking is controlled by a snib in the front plate Using of the snib is normally blocked. The snib is released by turning the key When the snib is in its up position, the lock will deadlock when the door closes and can only be opened by a key from the outside or by a lever handle or panic bar from the inside When the snib is in its down position, the latchbolt is retained inside the lock case

The door is opened from outside with a door pull The lock case fulfills the requirements of the European standard for exit products SFS-EN179 and SFS-EN1125 and the requirements of the lock case standard SFS-EN12209 The lock is always opened from the inside by a lever handle or panic bar The lock is deadlocked always when the door is closed The latchbolt protrudes 14 mm

Security mortice lock (security grade 5 according to EN 12209) with a hardened bolt and drilling protection For Scandinavian range cylinders The deadbolt has 20 mm bolt throw The deadbolt is locked and retracted by turning the key 360° or thumbturn 90° The key can only be removed when the bolt is fully locked or retracted The latchbolt is retracted by the lever handles only Fire resistance : suitable for fire doors

Function is determined by sliding snib on forend When the snib is in its up position, the lock will deadlock when the door is closed and can only be opened by a key or by the thumbturn When the snib is in its middle position, the lock will latch normally, but can be opened by the handles as well as the key and the thumbturn When the snib is in its down position, the latchbolt is retained inside the lock case

Primarily for doors which must always be latched (e.g. fire doors) and where deadlocking is needed Function is determined by a sliding snib on forend When the snib is in its up position, the lock will deadlock when the door closes and can only be opened by a key or by the thumbturn When the snib is in its middle position, the lock will latch when the door closes but can be opened by the handles The down position of the snib is not in use Sliding snib is released only when turning the key (or thumbturn) Microswitch version The switch changes it’s status when the latchbolt is fully extended Fire resistance

The door is opened from outside with a door pull The lock case fulfills the requirements of the European standard for exit products SFS-EN179 and SFS-EN1125 and the requirements of the lock case standard SFS-EN12209 The lock is always opened from the inside by a lever handle or panic bar Deadlocking is controlled by a snib in the front plate Using of the snib is normally blocked The snib is released by turning the key When the snib is in its up position, the lock will deadlock when the door closes and can only be opened by a key from the outside or by a lever handle, push pad, or panic bar from the inside When the snib is in its down position, the latchbolt is retained inside the lock case

The door is opened from outside with a door pull The lock case fulfills the requirements of the European standard for exit products SFS-EN179 and SFS-EN1125 and the requirements of the lock case standard SFS-EN12209 The lock is always opened from the inside by a lever handle or panic bar The lock is deadlocked always when the door is closed The latchbolt protrudes 14 mm Fire resistance

The door is opened from outside with a door pull The lock case fulfills the requirements of the European standard for exit products SFS-EN179 and SFS-EN1125 and the requirements of the lock case standard SFS-EN12209 The lock is always opened from the inside by a lever handle or panic bar The lock is deadlocked always when the door is closed Latchbolt protrudes 17 mm Fire resistance

The bolt protrudes 21 mm The lock is operated by a key or by a thumbturn The lock is used in places where the door must deadlock every time it is closed Fire resistance

The latchbolt is deadlocked when both triggering bolt and latchbolt are retained inside the lock case The deadlocking is controlled by a snib in the forend The lock case is fitted with at feature to prevent unauthorized use of the snib The snib can be moved by turning first the key or thumbturn When the snib is in its up position, the door will deadlock when closed, and can be opened by a key or by the thumbturn When the snib is in its down position, the lock can be also be opened by the handles Fire resistance

The latchbolt is deadlocked when both triggering bolt and latchbolt are retained inside the lock case Deadlocking is controlled by a snib in the front plate The lock cases fitted with at feature to prevent unauthorized use of the snib The snib can be moved by turning first the key or thumbturn The lock has no lever handle operation When the snib is in its up position, the door deadlocks when it closes and can only be opened by a key and by the thumbturn When the snib is in its down position, the latchbolt is retained inside the lock case

Lock case with an automatically deadlocking latchbolt The lock has no lever handle operation The bolt is opened with either a key or a thumbturn Fire resistance

The bolt can be locked inside the lock case The deadlocking can be controlled by a sliding snib on the forend of the lock case When the snib is in its up position, the lock deadlocks and can only be opened by a key or by the thumbturn When the snib is in its down position, the bolt is locked inside the lock case

Security lock (SFS 7020 grade 3 and comparable with security grade 5 according to EN 12209) for solid doors The lock case works with the 4690, 4691, LP711, LP714, LP721, and LP731 striker plates

Security lock (SFS 7020 grade 3 and comparable with security grade 5 according to EN 12209) for solid doors Microswitch version. The switch changes its status when the bolt is deadlocked The lock case works with the 4690, 4691, LP711, LP714, LP721, and LP731 striker plates

Security lock (SFS 7020 grade 3 and comparable with security grade 5 according to EN 12209) For solid doors

The BEAT Key Deposit enables keyless access to properties with a smartphone via a Bluetooth Low Energy (BLE) connection. The BEAT Key Deposit is designed to perform in harsh conditions with its IP66/68 and IK10 certifications. Property managers can conveniently grant different user groups access to properties via the users’ mobile phones, without the need for unnecessary key logistics and access control.

ABLOY EA453 is a control unit for the EL874 and EL875 lockcases.

Delay unit for electric locks Switching AC to DC and delay adjustment e.g. with door phones

ABLOY PE911 is a mechanical lock package for passive leaf doors.

The lock can be opened either with a key (outside and inside) or by using an emergency thumbturn Automatic deadlocking when the door is closed Microswitch version The switch changes it’s status when the latchbolt is fully extended

The door is opened from outside with a lever handle The lock case fulfills the requirements of the European standard for exit products SFS-EN179 and SFS-EN1125 and the requirements of the lock case standard SFS-EN12209 The lock is always opened from the inside by a lever handle, push pad or panic bar The latchbolt protrudes 14 mm Deadlocking is controlled by a snib in the front plate Using of the snib is normally blocked. The snib is released by turning the key When the snib is in its up position, the lock will deadlock when the door closes and can only be opened by a key from the outside or by a lever handle or panic bar from the inside When the snib is in its down position, the lock will latch normally and the lock can be opened also by the exterior handle Microswitch version The switch changes the status when latchbolt is deadlocked

Lock case for Scandinavian range cylinders The deadbolt is locked and retracted by turning the key or thumbturn 90° A further 5° turn will retract the latchbolt as well The latchbolt is retracted also by the lever handles

Security mortice lock case (security grade 5 according to EN 12209) with hardened deadbolt and drilling protection The deadbolt has a 20 mm bolt throw The deadbolt is locked and retracted by turning the key or thumbturn 360° The key can only be removed when the deadbolt is fully locked or retracted

The lock can be opened from outside by a key and inside by a handle The lock deadlocks automatically when the door closes Fire resistant

Primarily for doors which must always be latched (e.g. fire doors) and where deadlocking is needed Function is determined by a sliding snib on forend When the snib is in its up position, the lock will deadlock when the door closes and can only be opened by a key or by the thumbturn When the snib is in its middle position, the lock will latch when the door closes but can be opened by the handles The down position of the snib is not in use Sliding snib is released only when turning the key (or thumbturn) Fire resistance
