LILIN PIH-2146XP Internal Colour Dome Camera With 3.8 ~ 9.5mm Varifocal Lens

Technical Specification

This product model is not available in this region

Features:

Make: LILIN
Model code: PIH-2146XP
Chip Inch Size: 1/3
Color Type: Color
Resolution TVL: 540

Additional info:

RCA video connector for easy adjustment or site with 3-Axis camera construction. Optically perfect impact and dust resistant polycarbonate dome cover.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	LILIN
Manufacturer	LILIN
Category	Video Surveillance>Dome cameras
Model code	PIH-2146XP
Chip Inch Size	1/3
Color Type	Color
Resolution TVL	540
Dome Type	Variable Focus
Sensitivity lux	0.05
Indoor/Outdoor	Indoor
Electrical Specifications	Voltage: 12 V DC / 24 V AC Power Consumption: 2.5 W, 3 W
Focal length	3 ~ 9
Back Light Compensation	Yes
Auto Gain Control	Yes
White Balance	Yes
S/ N (Signal/ Noise) Ratio dB	>50
Synchronisation	Internal
Signal Mode	PAL
Video Output	1 Vpp, CVBS, 75 Ohms
Physical Specifications	Dimensions mm: 120 x 55 Weight g: 300
Environmental Specifications	Operating Temp ^oC: -10 ~ +50
Additional info	RCA video connector for easy adjustment or site with 3-Axis camera construction. Optically perfect impact and dust resistant polycarbonate dome cover.
