IDIS DE-1108 8 Channel Video Encoder

Technical Specification

Features:
  • Make: IDIS
  • Model code: DE-1108
  • Video Inputs: 8
  • Audio Input: Yes
  • Compression Type: H.264
Read more
Additional info:

IDIS DE-1108 is a video encoder that supports PTZ with RS485 port, 4 audio input ports, quadruple stream, and 8 analog camera input ports.

Read more
Make IDIS
Manufacturer IDIS
Model code DE-1108
Video Inputs 8
Audio Input Yes
Compression Type H.264
Resolution TVL 704 x 576
Image per second (IPS) 30
Control PTZ
Physical Specifications Dimensions mm: 166 x 44 x 145
Weight g: 700
Electrical Specifications Voltage: 12 V DC
Video Inputs Overview BNC composite
Additional info IDIS DE-1108 is a video encoder that supports PTZ with RS485 port, 4 audio input ports, quadruple stream, and 8 analog camera input ports.
Download PDF version Download PDF version
