Video Encoders

VITEC, a market-renowned provider of IPTV, video streaming, and digital signage solutions, and RFmondial, a specialist in wireless transmission technology, have announced a groundbreaking achievement: the world's first demonstration of ultra-low latency (below 100 ms) video streaming over DECT NR+, the new non-cellular 5G standard. Achieved as part of the Sennheiser-led Franco-German-backed project MERCI, the demonstration took place at a public workshop in Hannover, Germany on April 19, 2024. Potential of DECT NR+ VITEC and RFmondial joined forces to unveil the potential of DECT NR+ for wireless video transmission As partners in the MERCI project, VITEC and RFmondial joined forces to unveil the potential of DECT NR+ for wireless video transmission.  VITEC’s market-renowned video encoder and decoder – renowned for exceptional energy efficiency and industry-low glass-to-glass latency – and RFmondial’s compact and optimized NR+ implementation (based on the Nordic chipset) combined to demonstrate to workshop attendees robust HD video streaming with latency down to 50 ms glass to glass over ranges of up to 100 meters. Simplicity of NR+ setup Eric Deniau, VITEC’s SVP R&D, commented: “This demonstration shows that Ultra-Low Latency wireless video transmission is now made simple even in very demanding environments, where today complex dedicated technical means are needed.” Jens Schroeder, RFmondial’s Managing Director, added: “The simplicity of NR+ setup, which does not require infrastructure deployment, together with its robust and high-performance capabilities, make it an ideal solution for wireless video connectivity in applications such as public venues, industrial or medical environments.” Focused on two use cases The MERCI project has support from the German and French governments as part of their 5G programs, with work focused on two use cases where these capabilities will be needed: Public venue displays and remote video production where video quality and display latency are key factors. Industrial robots and remote vehicle operation where end-to-end latency and secure transmissions are essential. Adoption of wireless video transmission NR+ enables ultra-low latency and ultra-reliable wireless connectivity for demanding network environments. Based on proven capabilities, it is anticipated that future silicon implementations of NR+ will allow for more throughput and improved robustness (as defined by the ETSI standard) to fulfill the requirements for wider adoption of wireless video transmission.  Combined with the next-generation high efficiency/low latency/low footprint video coding technology VITEC is currently working on, unprecedented performance will be possible, making the combination a perfect fit for many use cases where wireless video connectivity is currently lacking a suitable solution.

VuWall, a technology pioneer in video wall control systems and unified visualization solutions, proudly announces significant enhancements to its VuStream 150 H.264 HDMI video encoder. The VuStream 150, part of the VuStream series of encoders and decoders, seamlessly integrates with the PAK video wall, KVM nodes, and VuScape controllers, while being centrally configured and managed by the TRx centralized management software platform. Cost-effective solutions "Our commitment to continual enhancements across all our AV-over-IP products aims to provide our customers with the highest quality and most cost-effective solutions," said Fadhl Al-Bayaty, Vice President of Product Management at VuWall. "The improvements made to the VuStream 150 ensure that every aspect of performance and flexibility not only meets but exceeds expectations, empowering seamless content distribution, control, and management for years to come." VuStream 150 encoder The versatility extends to its streaming capabilities, effortlessly enabling unicast or multicast transmission The latest VuStream 150 encoder appliance supports HDMI signals at resolutions up to 3840x2160@60Hz and supports 4:4:4 pass-through, as well as 4:2:0 and 4:2:2 encoding and streaming. This versatility extends to its streaming capabilities, effortlessly enabling unicast or multicast transmission to PAK processing nodes configured for various setups, including operator stations or expansive video walls, VuScape video wall controllers, and common media players like VLC.  PoE, NDAA Boasting high-quality UHD encoding, a sleek and compact design, Power over Ethernet (PoE) support, and seamless compatibility with third-party software decoding, the VuStream 150 is reshaping the landscape of video-over-IP solutions. Moreover, the VuStream 150 is NDAA (National Defense Authorization Act) and TAA (Trade Agreements Act) compliant, adhering to the provisions outlined in the National Defense Authorization Act and eligible for procurement by the United States government, respectively. Additionally, as part of the VuWall ecosystem, VuWall, including its TRx Centralized Management Platform, is SOC 2 compliant, a testament to the company's commitment to top-tier information security practices, policies, and procedures.

VITEC, a market-pioneering provider of IPTV, video streaming and digital signage solutions, is launching the MGW Diamond-H 4K HDMI encoder to further enhance its broad portfolio of HEVC encode and decode products. “VITEC is proud to introduce the MGW Diamond-H, a powerful compact 4K HDMI Encoder demonstrating our commitment to innovation and meeting the evolving needs of our customers,” says Richard Bernard, Head of Product Management, at VITEC. “With its impressive encoding capabilities, seamless integration features, and Power over Ethernet support, the MGW Diamond-H opens up new possibilities for IPTV distribution and video contribution across various industries." VITEC's portable HEVC encoder MGW Diamond-H ensures a smooth workflow and enhanced connectivity with existing video equipment The MGW Diamond-H, a portable 4K HDMI Encoder is a significant addition to VITEC's portable HEVC encoder product line, setting a new standard for quality, efficiency, and integration. With the ability to encode up to 4 channels from two HDMI inputs, the MGW Diamond-H empowers users to capture and stream content with unparalleled quality and minimal latency. The unit is designed to facilitate integration into existing setups. Featuring HDMI loop through, the MGW Diamond-H ensures a smooth workflow and enhanced connectivity with existing video equipment. For optimal reliability and power efficiency, the MGW Diamond-H can be powered via Power over Ethernet, streamlining installations and reducing the need for additional power sources. Demand for 4K video encoding VITEC is a pioneer in video encoding for many different workflows from military, enterprise, broadcast, education, and sports venues.  The MGW Diamond-H meets the growing demand for 4K video encoding, while delivering low-latency delivery of high-quality video in an efficient, compact form factor.

Matrix is dedicated to pioneering the way in cutting-edge security and telecommunications solutions, both at a national and international scale, guided by extensive research. At the g-tech 2023 event, Matrix displayed an extensive array of customer-centric products in the fields of telecommunications, video surveillance, access control, and time attendance. During this event, Matrix introduced its full range of IP Video Surveillance solutions, including high-performance NVRs designed for server operation, cameras certified by UL, the Matrix VMS, and additional offerings. Matrix addresses the unique challenges confronted by organizations, such as optimizing bandwidth, reducing storage costs, managing multiple office locations, and implementing responsive security measures. Matrix provides comprehensive solutions tailored to meet all organizational needs. NEMA Certification Exhibited cameras had Turret, Dome, Bullet, and PTZ Cameras, with resolves ranging from 2 MP to 8 MP The exhibited cameras included Turret, Dome, Bullet, and PTZ Cameras, with resolutions ranging from 2 MP to 8 MP. These cameras are proudly certified by UL, a universally acknowledged safety standard, and have obtained NEMA Certification, offering protection against environmental threats. This guarantees sharp and clear images for meticulous scenario analysis. Furthermore, Matrix presented its enterprise-grade NVRs that operate on servers, featuring pre-installed Video Management Software that supports redundancy and allows for the use of hot-swappable hard drives (HDD/SSD) with a maximum capacity of 144 TB. This technological innovation comprehensively tackles all aspects of organizational security needs. Matrix's access control products In the domain of access control and time attendance, Matrix distinguishes itself as the exclusive manufacturer that internally produces all components, including panels, door controllers, readers, and software, without relying on external sources. In the access control sector, Matrix showcased its adaptable site controller, known as the COSEC PANEL200P, with the ability to oversee as many as 25,000 users and 255 COSEC door controllers. Furthermore, Matrix unveiled its cutting-edge access door controller, the COSEC ARC DC200P, which offers numerous benefits compared to conventional access control terminals. Featuring Power over Ethernet (PoE) functionality and various mounting alternatives, this controller can be conveniently installed, even in constrained areas, reducing the requirement for extensive wiring. This event offered a comprehensive presentation of Matrix's entire lineup of access control products. Matrix featured COSEC ARGO FACE Matrix introduced the state-of-the-art COSEC ARGO FACE, a facial recognition-based door controller In the realm of time attendance solutions, Matrix featured the COSEC VEGA FAXQ, a specialized Biometric Attendance Device (AEBAS) designed specifically for government agencies. This device securely utilizes Aadhaar data from the UIDAI server to ensure precise attendance tracking for Indian government employees. Additionally, Matrix introduced the state-of-the-art COSEC ARGO FACE, a facial recognition-based door controller renowned for its exceptional accuracy, rapid identification speed of less than 0.5 seconds, and an impressive user capacity of 50,000. These devices offer versatile connectivity options, including Wi-Fi, Power over Ethernet (PoE), and Ethernet, catering to the diverse requirements of contemporary organizations. At g-tech 2023, Matrix displayed its Telecom offerings, which encompassed the IP-PBX- ETERNITY NENX, as well as our entry-level IP phone-SPARSH VP210. Range of telecom solutions Besides Telecom products, Matrix also showcased a range of telecom solutions tailored to specific industries. In the field of telecommunications, Matrix holds a unique position as the exclusive OEM offering a wide array of business communication products and solutions. Kaushal Kadakia, Marketing Head states, “Through this event, one of our major aims is to connect with organizations and system integrators, present our proven products and solutions, and demonstrate how Matrix caters to various verticals through our enterprise-grade solutions.”

At IACP 2023, on booth 1127, i-PRO Americas Inc., (formerly a division of Panasonic), a pioneer in professional security solutions for surveillance and public safety, will demonstrate its latest range of security solutions for law enforcement professionals. i-PRO’s comprehensive portfolio of public safety and law enforcement solutions includes body-worn cameras, in-vehicle video systems, interview room video solutions, as well as on-premises and cloud-hosted digital evidence management solutions. Features of Genetec Clearance™ i-PRO customers maintain full control of their DEMS and VMS strategies, with full-featured choices In addition to the extensive range of imaging and evidence management offerings, the company specializes in advanced, AI-driven software and intelligent analytics, such as automated redaction to protect personal privacy. i-PRO is proud of its open-platform approach to public safety and security solutions, supporting tight integration with partners like Genetec to create CloUDE℠, a digital evidence management system that utilizes the features of Genetec Clearance™.  i-PRO customers maintain full control of their DEMS and VMS strategies, with full-featured choices using traditional servers and storage, hybrid storage solutions, or cloud-hosted services. VMS dual-mode architecture At IACP, attendees will learn about i-PRO’s latest Interview Room Video Solution. The system is simple to operate and offers automated activation to ensure every interview is recorded. The new VMS dual-mode architecture supports multiple room monitoring and ensures critical video and audio evidence is captured reliably, every time. “We design our public safety products specifically for the on-the-job rigors of police, fire, and EMS crews. i-PRO products deliver unparalleled reliability with a less than 1% failure rate for in-car and body-worn camera systems since 2004, affirming our commitment to excellence,” said David O’Connor, Director, i-PRO Public Safety Division. “We know how important cybersecurity and regulatory compliance are to our customers, so we develop complete solutions that automate processes to enable users to focus on the job, not the technology.” Body-worn camera solutions Cameras themselves are built to the choosy MIL-STD 810H military measure with an IP67 rating i-PRO’s BWC4000 body-worn camera features a unique 12-hour field-swappable battery, providing law enforcement and security officers with extended camera operation without having to deal with cumbersome charging cables. Officers can quickly tag videos with essential metadata using an easy-to-use LCD menu. Options such as automated activation in response to specific events such as drawing a weapon guarantee that important video evidence is available every time.  Designed to provide officers with a more durable and reliable way to capture video and audio evidence in virtually any conditions, i-PRO body-worn cameras utilize the industry-standard Klick Fast™ mounting system which provides many options to easily secure the camera. The cameras themselves are built to the demanding MIL-STD 810H military standard with an IP67 weather-resistant rating. In-car video system i-PRO’s in-car video (ICV) system, the ICV4000, takes in-car video technology into the future with a powerful video processing unit (VPU4000), wireless networking, enhanced security features, and improved image quality. The system employs MPEG-4 recording, eliminating the need for proprietary media formats to provide a more streamlined approach for reviewing and sharing video. The ICV4000 can utilize 4G/5G connectivity from a mobile router or the squad MDT (Mobile Data Terminal) for evidence uploads and live streaming. With support for up to five total cameras and several options for front-view cameras, the ICV4000 can provide 1080p Full HD recording with a wider field of view and 360-degree coverage around a vehicle. Additionally, the system incorporates embedded bluetooth (BLE) and two wireless LAN modules to support seamless integration with i-PRO’s BWC4000. The system supports up to 16 triggers for system activation or status indicators. Panoramic front cameras for police vehicles IACP attendees will be able to see WV-VCF41P 4K Panoramic Front Camera for police vehicles IACP attendees will also be able to see the WV-VCF41P 4K Panoramic Front Camera for police vehicles. A component of i-PRO’s powerful in-car video (ICV) system, the camera is ideal for law enforcement agencies seeking wide-angle coverage and high-resolution capture of video evidence from the vehicle. Unlike traditional forward-facing cameras, the WV-VCF41P provides a full 150-degree field of view. The innovative lens is specifically designed to minimize distortion and edge warping, resulting in the widest angle offered. Behind the lens, the camera’s 4K sensor is i-PRO’s highest resolution sensor for mobile video evidence applications. With support for detailed forensic zooming into areas of interest without image blurring, the WV-VCF41P presents the clearest possible evidence. Unified digital evidence management i-PRO’s in-car video system and law enforcement cameras enable officers to easily upload video evidence into the CloUDE digital evidence management system (powered by Genetec Clearance) using either Wi-Fi, a mobile router, or a mobile data terminal with a cellular connection. CloUDE allows officers and investigators to store, manage, review, and share evidence from their in-vehicle or body-worn cameras efficiently and easily from within a single application.  Authorized individuals can share cases and digital video evidence with cooperating agencies, prosecutors, attorneys, or members of the media. Secure access and chain of custody are controlled through straightforward policies managed in the application. Additionally, advanced logging creates an audit trail of all user actions, available for management review at any time.

With Ensenso C, IDS presents a stereo vision camera that not only generates 3D point clouds, but also delivers 2D images in color (RGB) thanks to an additionally integrated image sensor. This enables realistic 3D images and supports subsequent processes–for example when the images are to be further processed to perform sorting tasks. Its compact housing is completely enclosed and complies with protection class IP65/67. This reliably protects the components from environmental influences and vibrations. In addition, the camera is delivered pre-configured and is thereby ready to use. Ensenso C is suitable for the automation of many industrial processes, such as in quality control, on assembly lines, or for picking tasks. Features of 3D camera Camera is designed in such a way that temperature-related deviations of depth values are reduced Initially, the 3D camera is available with a baseline of approx. 240 mm; soon additional models with a baseline of approx. 455 mm will be offered. Thanks to the combination of powerful 200 W projector power and the high resolution of 5 MP, the camera delivers precise data even in large-volume applications. With the large baseline and small field of view, the models achieve a reproducible Z-accuracy of 0.2 mm at a 2 m object distance.  Moreover, the camera is designed in such a way that temperature-related deviations of the depth values are reduced to a minimum: deviations at 30 cm distance at 10°C temperature change less than 0.075 mm, for example. A diffused white light LED also supports with 2D color imaging in applications with changing ambient light conditions. Ensenso selector The Ensenso C fits seamlessly into the 3D camera range from IDS. The Ensenso product line is specifically designed for industrial requirements and combines precision with cost-effectiveness. Whether with fully integrated housing, modular design, or integrated data processing: The Ensenso N, S, X, XR and as of now Ensenso C families provide solutions for a wide range of requirements from bin picking to quality control. Users can consult the Ensenso selector on the IDS website to find the right model for their particular application.

Daniel May of Consort reviews the integration of access control systems in healthcare settings, outlining the benefits and key considerations decision-makers must make throughout product specifications.  From patient safety and traversal to the protection of sensitive data and pharmaceuticals, healthcare environments are faced with several operational challenges. And where security remains at the forefront of decision-making, modern access control systems may often hold the answers. Physical security systems Hospitals in particular have developed into multi-faceted spaces that house hundreds to thousands of patients, staff, and visitors at any one time. In England for example, research has found in the three months leading to June 2023, an average of 44,626 people visited major hospital A&E departments each day, with over 16 million attendances typically recorded over the course of a year-not to mention an additional nine million logged at other minor units. For any building, this level of sustained footfall can request severe security difficulties For any building, this level of sustained footfall can invite severe security tests. With that, the need to deploy effective physical security systems in healthcare is clear. And so, as access control continues to become more readily adopted and new products enter the market, decision-makers are reminded to consider the requirements of their building, ensuring they select the solutions most suited to their settings and budget. Security controlled Patient safety will always remain the top priority in healthcare settings, and where matters of health and social care come into question, a diverse set of professional regulatory bodies are tasked with setting and maintaining high standards. When it comes to healthcare premises specifically, patient security and perimeter security often come hand in hand and are amongst the most pressing of challenges that decision-makers must face. To help address operational planning and potential design concerns in the NHS, the Health Building Note (HBN), provides general design guidance for healthcare buildings under HBN 00-01-citing the use of access control measures as a way of maintaining security and protecting the safety of patients, staff, and visitors. Use of access control Hospital buildings control varied levels of access for a number of security purposes Hospital buildings, for example, must control varied levels of access for a number of operational and security purposes. Routine scenarios exist where vulnerable patients are under monitoring and thus refrained from exiting the premises for their own safety, while at the same time, permitted staff must be able to reach their patients and medicines when required. For this, the use of access control is key. Equally, access credentials can also help management teams keep track of those who may be entering or exiting rooms with equipment and pharmaceutical supplies, deterring any unwanted visitors and opportunists in the process. Incorporation of access control systems On a similar note, regulations have set a minimum standard for how personal data should be stored and managed in healthcare environments, giving decision-makers an added responsibility to regulate staff-controlled areas with patient medical records. While instances of personal data breaches are rare, healthcare facilities and professionals are at legal risk should confidential data be found misused or missing. As such, the incorporation of access control systems has become essential in keeping data storage areas secure, with intuitive online systems capable of permitting access to staff with the correct credentials while simultaneously tracking who has requested clearance at digital entry points. HBN guidance Healthcare experts are better fitted to control the sheer volume of people entering and exiting To function effectively, healthcare facilities must always be perceived as safe places by the people who reside within them, and as HBN guidance implies, a unified physical security system can help address key safety and security concerns while enhancing patient and staff experience. Opportunely, access control systems are more accessible and adaptable than ever and combine several technologies such as mechanical locks and automatic doors with electronic access credentials in the form of smartphone apps, badge readers, and biometric scanners.  By integrating these systems into the building’s existing infrastructure, healthcare professionals are better equipped to control the sheer volume of people entering and exiting the premises without impairing the general flow of movement and coordination around the facility. Better by design Despite the clear benefits offered to healthcare facilities, there are a number of considerations to be mindful of when choosing an access control solution. Poorly implemented systems can have an adverse effect on security and functionality - quickly costing healthcare organizations time and budget to rectify and replace the inadequate products that don’t meet the building’s requirements. For that reason, decision-makers and design teams are reminded that there is no single solution that fits all healthcare buildings. As such, it’s crucial for decision-makers to understand the systems that are being put in place throughout each of the touchpoints in their facility. Clear collaboration is required during periods of specification, where together, teams can ensure the selected product works on all angles, from meeting fire safety and sustainability standards to aesthetics and scalability. Modern access control products Scalability is a key area that decision-makers must review when selecting access control systemsFrequently overlooked, scalability is a key area that decision-makers must review when selecting access control systems. Such is their diverse nature; healthcare facilities can often change and develop as years go by, and by selecting a system that facilitates growth, such as a cloud-based solution-security and efficiency is long-established. While modern access control products are known for seamless integration, there are some systems that may restrict the ability to use different vendors throughout the remainder of the building’s infrastructure. This, in effect, causes a monopolization of products throughout the estate, which can have an adverse effect on growth by increasing costs and reducing the levels of service associated with the security system already in place. Improve security and safety A scalable and reliable access control system will continue to improve security and safety by adapting to a building’s new requirements-and all while having minimal impact on its operational network.  And so, while technology will no doubt continue to influence and transform the access control market, healthcare facilities and their professionals must continue to remain educated on their own systems, ensuring they have the best options in place to keep their patients, staff, and visitors safe and secure for years to come.

Security systems represent a significant investment, yet many organizations still only use a small percentage of their physical security systems’ capabilities. That’s before we even begin to consider the different ways that the likes of video, access control, and ANPR can add additional value beyond security by serving the needs of other business functions. Whether that be to obtain additional insight, streamline compliance, or drive operational efficiencies.  Consumption gap When users aren’t tapping into the full power of the solution they bought, they aren’t realizing their full return on investment. This creates a consumption gap. It’s a situation that has the potential to go in one of two very different directions. A misunderstanding of a system, its capabilities and functionality can quickly result in user dissatisfaction Left unchecked a consumption gap can create frustration for system integrators, manufacturers, and end users alike. A misunderstanding of a system, its capabilities and functionality can quickly result in user dissatisfaction. Leading to a greater likelihood that they’ll look to change or focus investment into overlapping and likely competing solutions. Customers’ security goals Addressed appropriately it can help manufacturers, system integrators, and end users to build trusted partnerships in which everybody wins. Understandably, systems integrators are primarily focused on installation—delivering reliable solutions that meet customers’ security goals to ensure their long-term success. However, engagement can go beyond deployment. Closing the consumption gap can be a strategic way to differentiate yourself from competitors. The deeper you understand your customer’s business, the better advice you’re able to offer—and the stronger the partnership you form.  Why do consumption gaps exist?  For customers, finding the time to learn multiple capabilities of a security system can be time-consuming. Often, taking advantage of new tools and solutions takes a backseat to the urgency of daily tasks. Often, taking advantage of new tools and solutions takes a backseat to the urgency of daily tasks   There are many reasons why customers may not be taking full advantage of the features available to them in their security platform. They may feel overwhelmed by a steep learning curve after deployment and might delay diving into the additional system features. Sometimes, there might be a lack of awareness of the technology’s full capabilities, and despite a willingness to learn, there are few options for training. Often, it can simply be they are not aware of the benefits of their system or are too busy with day-to-day and urgent tasks to learn other features.   Bridging the consumption gap  Systems are built to deal with a wide variety of use cases and broaden market appeal, but the goal isn’t to get everyone to use all the features of every product. You want to guide your customers toward the features and functionality that best meet their needs. This could entail reducing the friction they experience in their day-to-day operations, solving unique issues related to their business, or addressing their most important challenges.   Having these conversations with your customers deepens your relationship and can organically open up new revenue streams. Continuous engagement allows you to recommend other relevant products or services that they may find helpful. Customized training plan Customers can learn at their own pace and gradually expand their understanding of their system Furthermore, customers are often not able to implement all features at once. You can help by proposing a plan to gradually evolve systems and processes over time. This could include a customized training plan to get the most value from their investment.   Some manufacturers are also now providing learning management tools that system integrators can pass on to their customers. Customers can learn at their own pace and gradually expand their understanding of their system in accordance with their bandwidth. This allows them to get more out of their system.  Simplifying deployment   With the right software partners, systems integrators can focus on solving customer problems, not reactively troubleshooting issues. Look for manufacturers who offer good support systems for integrators. This includes not only quality technical support but also configuration and training services you can build on. Look for partners that offer tools and consultation services you can use to complement your value-added services, either to spend less time on the basics or for specialized expertise on complex projects.  Beyond support and services, one telling sign is the configuration interface and tools that you as an integrator will primarily interact with. Ask yourself whether the manufacturer invests in their back-end tools and their primary user interface. Is there a noticeable difference between these two interfaces in terms of look and feel? Does one feel more dated?  Widening consumption gap  The harder it is to implement upgrades, the more reticent customers are to make the changes If the end user interface is easy to use but changes on the back end are difficult, the resulting friction can contribute to the widening consumption gap. It can become too time-consuming or difficult to upgrade or make changes to the system. The harder it is to implement upgrades, the more reticent customers are to make the changes.  Configuration should be painless. If the system has a solid graphical user interface, you’ll be able to interact with the software in a fluid and intuitive way. When the system is intuitive for both you and your customers, you spend less time on setup and training. You can invest more attention in value-added activities.   Conclusion  A consumption gap could be a sign that technological innovation is outpacing people's ability to implement them in their day-to-day lives. You can work with your customers to simplify the adoption of the innovations so they can more easily implement them and realize the full value of their investment.  By reviewing opportunities to bridge the consumption gap for your customers, you increase the likelihood of growing and renewing your system and service contracts. You also build relationships as a trusted partner. Customers will turn to you when looking to expand their security system and proactively solve new and incipient problems.

The role of storage in video surveillance systems has  evolved, from a means of preserving evidence to an evidence search tool, and soon as the main data repository for predictive analytics. Old analog systems are now being replaced with massive multi-camera IT systems. Necessary storage volumes keep growing as video resolutions increase. 1K, 4K, and 8K megapixel cameras require such gigantic storage space that network video recorders (NVRs) can hardly handle more than a handful of them simultaneously. This Quantum white paper explains how you can efficiently circumvent this situation, showing a progressive migration path from current state-of-the-art IP video solutions, up to tomorrow’s storage-centric architectures. What's Inside? Typical VMS architectures Issues with NVRs Uses of video analytics and its impact on storage The benefits of multi-tier storage The future of video recording   Click Here to Download the White Paper Now!

When it comes to security cameras, the end user always wants more—more resolution, more artificial intelligence (AI), and more sensors. However, the cameras themselves do not change much from generation to generation; that is, they have the same power budgets, form factors and price. To achieve “more,” the systems-on-chips (SoCs) inside the video cameras must pack more features and integrate systems that would have been separate components in the past.  For an update on the latest capabilities of SoCs inside video cameras, we turned to Jérôme Gigot, Senior Director of Marketing for AIoT at Ambarella, a manufacturer of SOCs. AIoT refers to the artificial intelligence of things, the combination of AI and IoT. Author's quote “The AI performance on today’s cameras matches what was typically done on a server just a generation ago,” says Gigot. “And, doing AI on-camera provides the threefold benefits of being able to run algorithms on a higher-resolution input before the video is encoded and transferred to a server, with a faster response time, and with complete privacy.” Added features of the new SOC Ambarella expects the first cameras with the SoC to emerge on the market during early part of 2024 Ambarella’s latest System on Chip (SOC) is the CV72S, which provides 6× the AI performance of the previous generation and supports the newer transformer neural networks. Even with its extra features, the CV72S maintains the same power envelope as the previous-generation SoCs. The CV72S is now available, sampling is underway by camera manufacturers, and Ambarella expects the first cameras with the SoC to emerge on the market during the early part of 2024. Examples of the added features of the new SOC include image processing, video encoders, AI engines, de-warpers for fisheye lenses, general compute cores, along with functions such as processing multiple imagers on a single SoC, fusion among different types of sensors, and the list goes on. This article will summarize new AI capabilities based on information provided by Ambarella. AI inside the cameras Gigot says AI is by far the most in-demand feature of new security camera SoCs. Customers want to run the latest neural network architectures; run more of them in parallel to achieve more functions (e.g., identifying pedestrians while simultaneously flagging suspicious behavior); run them at higher resolutions in order to pick out objects that are farther away from the camera. And they want to do it all faster. Most AI tasks can be split between object detection, object recognition, segmentation and higher-level “scene understanding” types of functions, he says. The latest AI engines support transformer network architectures (versus currently used convolutional neural networks). With enough AI horsepower, all objects in a scene can be uniquely identified and classified with a set of attributes, tracked across time and space, and fed into higher-level AI algorithms that can detect and flag anomalies. However, everything depends on which scene is within the camera’s field of view. “It might be an easy task for a camera in an office corridor to track a person passing by every couple of minutes; while a ceiling camera in an airport might be looking at thousands of people, all constantly moving in different directions and carrying a wide variety of bags,” Gigot says. Changing the configuration of video systems Low-level AI number crunching would typically be done on camera (at the source of the data) Even with more computing capability inside the camera, central video servers still have their place in the overall AI deployment, as they can more easily aggregate and understand information across multiple cameras. Additionally, low-level AI number crunching would typically be done on camera (at the source of the data).  However, the increasing performance capabilities of transformer neural network AI inside the camera will reduce the need for a central video server over time. Even so, a server could still be used for higher-level decisions and to provide a representation of the world; along with a user interface for the user to make sense of all the data. Overall, AI-enabled security cameras with transformer network-based functionality will greatly reduce the use of central servers in security systems. This trend will contribute to a reduction in the greenhouse gases produced by data centers. These server farms consume a lot of energy, due to their power-hungry GPU and CPU chips, and those server processors also need to be cooled using air conditioning that emits additional greenhouse gases. New capabilities of transformer neural networks New kinds of AI architectures are being deployed inside cameras. Newer SoCs can accommodate the latest transformer neural networks (NNs), which now outperform currently used convolutional NNs for many vision tasks. Transformer neural networks require more AI processing power to run, compared to most convolutional NNs. Transformers are great for natural language processing (NLP) as they have mechanisms to “make sense” of a seemingly random arrangement of words. Those same properties, when applied to video, make transformers very efficient at understanding the world in 3D. Transformer NNs require more AI processing power to run, compared to most convolutional NNs For example, imagine a multi-imager camera where an object needs to be tracked from one camera to the next. Transformer networks are also great at focusing their attention on specific parts of the scene—just as some words are more important than others in a sentence, some parts of a scene might be more significant from a security perspective.  “I believe that we are currently just scratching the surface of what can be done with transformer networks in video security applications,” says Gigot. The first use cases are mainly for object detection and recognition. However, research in neural networks is focusing on these new transformer architectures and their applications. Expanded use cases for multi-image and fisheye cameras For multi-image cameras, again, the strategy is “less is more.” For example, if you need to build a multi-imager with four 4K sensors, then, in essence, you need to have four cameras in one. That means you need four imaging pipelines, four encoders, four AI engines, and four sets of CPUs to run the higher-level software and streaming. Of course, for cost, size, and power reasons, it would be extremely inefficient to have four SoCs to do all this processing. Therefore, the latest SoCs for security need to integrate four times the performance of the last generation’s single-imager 4K cameras, in order to process four sensors on a single SoC with all the associated AI algorithms. And they need to do this within a reasonable size and power budget. The challenge is very similar for fisheye cameras, where the SoC needs to be able to accept very high-resolution sensors (i.e., 12MP, 16MP, and higher), in order to be able to maintain high resolution after de-warping. Additionally, that same SoC must create all the virtual views needed to make one fisheye camera look like multiple physical cameras, and it has to do all of this while running the AI algorithms on every one of those virtual streams at high resolution. The power of ‘sensor fusion’ Sensor fusion is the ability to process multiple sensor types at the same time and correlate all that information Sensor fusion is the ability to process multiple sensor types at the same time (e.g., visual, radar, thermal, and time of flight) and correlate all that information. Performing sensor fusion provides an understanding of the world that is greater than the information that could be obtained from any one sensor type in isolation. In terms of chip design, this means that SoCs must be able to interface with, and natively process, inputs from multiple sensor types.  Additionally, they must have the AI and CPU performance required to do either object-level fusion (i.e., matching the different objects identified through the different sensors), or even deep-level fusion. This deep fusion takes the raw data from each sensor and runs AI on that unprocessed data. The result is machine-level insights that are richer than those provided by systems that must first go through an intermediate object representation. In other words, deep fusion eliminates the information loss that comes from preprocessing each individual sensor’s data before fusing it with the data from other sensors, which is what happens in object-level fusion. Better image quality AI can be trained to dramatically improve the quality of images captured by camera sensors in low-light conditions, as well as high dynamic range (HDR) scenes with widely contrasting dark and light areas. Typical image sensors are very noisy at night, and AI algorithms can be trained to perform excellently at removing this noise to provide a clear color picture—even down to 0.1 lux or below. This is called neural network-based image signal processing, or AISP for short. AI can be trained to perform all these functions with much better results than traditional video methods Achieving high image quality under difficult lighting conditions is always a balance among removing noise, not introducing excessive motion blur, and recovering colors. AI can be trained to perform all these functions with much better results than traditional video processing methods can achieve. A key point for video security is that these types of AI algorithms do not “create” data, they just remove noise and clean up the signal. This process allows AI to provide clearer video, even in challenging lighting conditions. The results are better footage for the humans monitoring video security systems, as well as better input for the AI algorithms analyzing those systems, particularly at night and under high dynamic range conditions. A typical example would be a camera that needs to switch to night mode (black and white) when the environmental light falls below a certain lux level. By applying these specially trained AI algorithms, that same camera would be able to stay in color mode and at full frame rate--even at night. This has many advantages, including the ability to see much farther than a typical external illuminator would normally allow, and reduced power consumption. ‘Straight to cloud’ architecture For the cameras themselves, going to the cloud or to a video management system (VMS) might seem like it doesn’t matter, as this is all just streaming video. However, the reality is more complex; especially for cameras going directly to the cloud. When cameras stream to the cloud, there is usually a mix of local, on-camera storage and streaming, in order to save on bandwidth and cloud storage costs. To accomplish this hybrid approach, multiple video-encoding qualities/resolutions are being produced and sent to different places at the same time; and the camera’s AI algorithms are constantly running to optimize bitrates and orchestrate those different video streams. The ability to support all these different streams, in parallel, and to encode them at the lowest bitrate possible, is usually guided by AI algorithms that are constantly analyzing the video feeds. These are just some of the key components needed to accommodate this “straight to cloud” architecture. Keeping cybersecurity top-of-mind Ambarella’s SoCs always implement the latest security mechanisms, both hardware and software Ambarella’s SoCs always implement the latest security mechanisms, both in hardware and software. They accomplish this through a mix of well-known security features, such as ARM trust zones and encryption algorithms, and also by adding another layer of proprietary mechanisms with things like dynamic random access memory (DRAM) scrambling and key management policies.  “We take these measures because cybersecurity is of utmost importance when you design an SoC targeted to go into millions of security cameras across the globe,” says Gigot. ‘Eyes of the world’ – and more brains Cameras are “the eyes of the world,” and visual sensors provide the largest portion of that information, by far, compared to other types of sensors. With AI, most security cameras now have a brain behind those eyes. As such, security cameras have the ability to morph from just a reactive and security-focused apparatus to a global sensing infrastructure that can do everything from regulating the AC in offices based on occupancy, to detecting forest fires before anyone sees them, to following weather and world events. AI is the essential ingredient for the innovation that is bringing all those new applications to life, and hopefully leading to a safer and better world.

A new generation of video cameras is poised to boost capabilities dramatically at the edge of the IP network, including more powerful artificial intelligence (AI) and higher resolutions, and paving the way for new applications that would have previously been too expensive or complex. Technologies at the heart of the coming new generation of video cameras are Ambarella’s newest systems on chips (SoCs). Ambarella’s CV5S and CV52S product families are bringing a new level of on-camera AI performance and integration to multi-imager and single-imager IP cameras. Both of these SoCs are manufactured in the ‘5 nm’ manufacturing process, bringing performance improvements and power savings, compared to the previous generation of SoCs manufactured at ‘10nm’. CV5S and CV52S AI-powered SoCs The CV5S, designed for multi-imager cameras, is able to process, encode and perform advanced AI on up to four imagers at 4Kp30 resolution, simultaneously and at less than 5 watts. This enables multi-headed camera designs with up to four 4K imagers looking at different portions of a scene, as well as very high-resolution, single-imager cameras of up to 32 MP resolution and beyond. The CV52S, designed for single-imager cameras with very powerful onboard AI, is the next-generation of the company’s successful CV22S mainstream 4K camera AI chip. This new SoC family quadruples the AI processing performance, while keeping the same low power consumption of less than 3 watts for 4Kp60 encoding with advanced AI processing. Faster and ubiquitous AI capabilities Ambarella’s newest AI vision SoCs for security, the CV5S and CV52S, are competitive solutions" “Security system designers desire higher resolutions, increasing channel counts, and ever faster and more ubiquitous AI capabilities,” explains John Lorenz, Senior Technology and Market Analyst, Computing, at Yole Développement (Yole), a French market research firm. John Lorenz adds, “Ambarella’s newest AI vision SoCs for security, the CV5S and CV52S, are competitive solutions for meeting the growing demands of the security IC (integrated circuit) sector, which our latest report forecasts to exceed US$ 4 billion by 2025, with two-thirds of that being chips with AI capabilities.” Edge AI vision processors Ambarella’s new CV5S and CV52S edge AI vision processors enable new classes of cameras that would not have been possible in the past, with a single SoC architecture. For example, implementing a 4x 4K multi-imager with AI would have traditionally required at least two SoCs (at least one for encoding and one for AI), and the overall power consumption would have made those designs bulky and prohibitively expensive. By reducing the number of required SoCs, the CV5S enables advanced camera designs such as AI-enabled 4x 4K imagers at price points much lower than would have previously been possible. “What we are usually trying to do with our SoCs is to keep the price points similar to the previous generations, given that camera retail prices tend to be fairly fixed,” said Jerome Gigot, Ambarella's Senior Director of Marketing. 4K multi-imager cameras “However, higher-end 4K multi-imager cameras tend to retail for thousands of dollars, and so even though there will be a small premium on the SoC for the 2X improvement in performance, this will not make a significant impact to the final MSRP of the camera,” adds Jerome Gigot. In addition, the overall system cost might go down, Gigot notes, compared to what could be built today because there is no longer a need for external chips to perform AI, or extra components for power dissipation. The new chips will be available in the second half of 2021, and it typically takes about 12 to 18 months for Ambarella’s customers (camera manufacturers) to produce final cameras. Therefore, the first cameras, based on these new SoCs, should hit the market sometime in the second half of 2022. Reference boards for camera manufacturers The software on these new SoCs is an evolution of our unified Linux SDK" As with Ambarella’s previous generations of edge AI vision SoCs for security, the company will make available reference boards to camera manufacturers soon, allowing them to develop their cameras based on the new CV5S and CV52S SoC families. “The software on these new SoCs is an evolution of our unified Linux SDK that is already available on our previous generations SoCs, which makes the transition easy for our customers,” said Jerome Gigot. Better crime detection Detecting criminals in a crowd, using face recognition and/or license plate recognition, has been a daunting challenge for security, and one the new chips will help to address. “Actually, these applications are one of the main reasons why Ambarella is introducing these two new SoC families,” said Jerome Gigot. Typically, resolutions of 4K and higher have been a smaller portion of the security market, given that they came at a premium price tag for the high-end optics, image sensor and SoC. Also, the cost and extra bandwidth of storing and streaming 4K video were not always worth it for the benefit of just viewing video at higher resolution. 4K AI processing on-camera The advent of on-camera AI at 4K changes the paradigm. By enabling 4K AI processing on-camera, smaller objects at longer distances can now be detected and analyzed without having to go to a server, and with much higher detail and accuracy compared to what can be done on a 2 MP or 5 MP cameras. This means that fewer false alarms will be generated, and each camera will now be able to cover a longer distance and wider area, offering more meaningful insights without necessarily having to stream and store that 4K video to a back-end server. “This is valuable, for example, for traffic cameras mounted on top of high poles, which need to be able to see very far out and identify cars and license plates that are hundreds of meters away,” said Jerome Gigot. The advent of on-camera AI at 4K changes the paradigm Enhanced video analytics and wider coverage “Ambarella’s new CV5S and CV52S SoCs truly allow the industry to take advantage of higher resolution on-camera for better analytics and wider coverage, but without all the costs typically incurred by having to stream high-quality 4K video out 24/7 to a remote server for offline analytics,” said Jerome Gigot. He adds, “So, next-generation cameras will now be able to identify more criminals, faces and license plates, at longer distances, for an overall lower cost and with faster response times by doing it all locally on-camera.” Deployment in retail applications Retail environments can be some of the toughest, as the cameras may be looking at hundreds of people at once Retail applications are another big selling point. Retail environments can be some of the toughest, as the cameras may be looking at hundreds of people at once (e.g., in a mall), to provide not only security features, but also other business analytics, such as foot traffic and occupancy maps that can be used later to improve product placement. The higher resolution and higher AI performance, enabled by the new Ambarella SoCs, provide a leap forward in addressing those scenarios. In a store setup, a ceiling-mounted camera with four 4K imagers can simultaneously look at the cashier line on one side of the store, sending alerts when a line is getting too long and a new cashier needs to be deployed, while at the same time looking at the entrance on the other side of the store, to count the people coming in and out. This leaves two additional 4K imagers for monitoring specific product aisles and generating real-time business analytics. Use in cashier-less stores Another retail application is a cashier-less store. Here, a CV5S or CV52S-based camera mounted on the ceiling will have enough resolution and AI performance to track goods, while the customer grabs them and puts them in their cart, as well as to automatically track which customer is purchasing which item. In a warehouse scenario, items and boxes moving across the floor could also be followed locally, on a single ceiling-mounted camera that covers a wide area of the warehouse. Additionally, these items and boxes could be tracked across the different imagers in a multi-headed camera setup, without the video having to be sent to a server to perform the tracking. Updating on-camera AI networks Another feature of Ambarella’s SoCs is that their on-camera AI networks can be updated on-the-fly, without having to stop the video recording and without losing any video frames. So, for example in the case of a search for a missing vehicle, the characteristics of that missing vehicle (make, model, color, license plate) can be sent to a cluster of cameras in the general area, where the vehicle is thought to be missing, and all those cameras can be automatically updated to run a live search on that specific vehicle. If any of the cameras gets a match, a remote operator can be notified and receive a picture, or even a live video feed of the scene. Efficient traffic management With the CV52S edge AI vision SoC, those decisions can be made locally at each intersection by the camera itself Relating to traffic congestion, most big cities have thousands of intersections that they need to monitor and manage. Trying to do this from one central location is costly and difficult, as there is so much video data to process and analyze, in order to make those traffic decisions (to control the traffic lights, reverse lanes, etc.). With the CV52S edge AI vision SoC, those decisions can be made locally at each intersection by the camera itself. The camera would then take actions autonomously (for example, adjust traffic-light timing) and only report a status update to the main traffic control center. So now, instead of having one central location trying to manage 1,000 intersections, a city can have 1,000 smart AI cameras, each managing its own location and providing updates and metadata to a central server. Superior privacy Privacy is always a concern with video. In this case, doing AI on-camera is inherently more private than streaming the video to a server for analysis. Less data transmission means fewer points of entry for a hacker trying to access the video. On Ambarella’s CV5S and CV52S SoCs, the video can be analyzed locally and then discarded, with just a signature or metadata of the face being used to find a match. No actual video needs to be stored or transmitted, which ensures total privacy. In addition, the chips contain a very secure hardware cyber security block, including OTP memory, Arm TrustZones, DRAM scrambling and I/O virtualization. This makes it very difficult for a hacker to replace the firmware on the camera, providing another level of security and privacy at the system level. Privacy Masking Another privacy feature is the concept of privacy masking. This feature enables portions of the video (say a door or a window) to be blocked out, before being encoded in the video stream. The blocked portions of the scene are not present in the recorded video, thus providing a privacy option for cameras that are facing private areas. “With on-camera AI, each device becomes its own smart endpoint, and can be reconfigured at will to serve the specific physical security needs of its installation,” said Jerome Gigot, adding “The possibilities are endless, and our mission as an SoC maker is really to provide a powerful and easy-to-use platform, complete with computer-vision tools, that enable our customers and their partners to easily deploy their own AI software on-camera.” Physical security in parking lots With a CV5S or CV52S AI-enabled camera, the camera will be able to cover a much wider portion of the parking lot One example is physical security in a parking lot. A camera today might be used to just record part of the parking lot, so that an operator can go back and look at the video if a car were broken into or some other incident occurred. With a CV5S or CV52S AI-enabled camera, first of all, the camera will be able to cover a much wider portion of the parking lot. Additionally, it will be able to detect the license plates of all the cars going in and out, to automatically bill the owners. If there is a special event, the camera can be reprogrammed to identify VIP vehicles and automatically redirect them to the VIP portion of the lot, while reporting to the entrance station or sign how many parking spots are available. It can even tell the cars approaching the lot where to go. Advantages of using edge AI vision SoCs Jerome Gigot said, “The possibilities are endless and they span across many verticals. The market is primed to embrace these new capabilities. Recent advances in edge AI vision SoCs have brought about a period of change in the physical security space. Companies that would have, historically, only provided security cameras, are now getting into adjacent verticals such as smart retail, smart cities and smart buildings.” He adds, “These changes are providing a great opportunity for all the camera makers and software providers to really differentiate themselves by providing full systems that offer a new level of insights and efficiencies to, not only the physical security manager, but now also the store owner and the building manager.” He adds, “All of these new applications are extremely healthy for the industry, as they are growing the available market for cameras, while also increasing their value and the economies of scale they can provide. Ambarella is looking forward to seeing all the innovative products that our customers will build with this new generation of SoCs.”

Arecont Vision is a company in transition to say the least. With its balance sheet burdened with debt, the company is seeking Chapter 11 bankruptcy protection and simultaneously being acquired by a private equity firm. The ‘new’ Arecont Vision that will emerge after several months when the process is complete will have a new owner, a clean balance sheet, and be poised to succeed in the competitive world of video surveillance, says Raul Calderon, Arecont Vision CEO and General Manager.Good companies go through restructuring, and the company will be better off after doing it. We will be able to lead” Ensuring Business Continuity An asset purchase agreement announced this week with an affiliate of Turnspire Capital Partners LLC involves the private equity firm acquiring Arecont Vision’s assets. To eliminate the debt, the company has initiated proceedings under Chapter 11 of the United State Bankruptcy Code in the District of Delaware. “We want the industry to know that we are restructuring our business and our financing,” says Calderon. “We are not going out of business. It is a financial restructuring more than anything.” Business will continue uninterrupted during the bankruptcy, he says, with debtor-in-possession (DIP) financing provided by Arecont Vision’s current secured lenders. Turnspire, as the ‘stalking-horse bidder’, sets the low-end bidding bar and guarantees the company will have new ownership at the conclusion of the process “Good companies go through restructuring, and the company will be better off after doing it,” Calderon adds. “We will be able to lead and innovate, to be stronger, better and faster once we finish.” For perspective, it is interesting to note that, in the broader business world, some well-known companies have emerged from Chapter 11 even stronger, such as Delta and American Airlines and General Motors. Investment In Product Development Previously Arecont Vision has been burdened by the costs of $80 million in debt the owners took on in 2014. The burden of that debt has limited the company’s flexibility to react to the more competitive industry landscape, and to implement strategies to reverse softening sales numbers in the last couple of years. “We couldn’t use the money in the company because we were servicing the debt,” says Calderon. “In order to be compliant with the enormous debt service, we made decisions to reduce head count and expenses.” “[The bankruptcy] will free up that money to invest in the organization,” he adds. “We will be able to make decisions for our future rather than the past, including investments in product development.” Focus and investment will be on key functions such as engineering, product development and sales Although there is an asset purchase agreement in place with Turnspire, there will also be an auction that could result in a higher bidder. Turnspire, as the ‘stalking-horse bidder’, sets the low-end bidding bar and guarantees the company will have new ownership at the conclusion of the process, either Turnspire or a company that outbids their offer. [UPDATE: An additional bid received from Costar Technologies and Costar Video Systems ensures that an auction will be held on July 9, 2018.] Calderon says Turnspire “shares our vision and will ensure an exciting future for the company.” The transaction is expected to move fast and close within a couple of months.Arecont Vision expects to continue to compete based on technology differentiation in the market, rather than on price Maintaining Technology Differentiation-Based Competition Turnspire Capital Partners is a private equity investor that is a ‘turnaround specialist’. Their website describes their role as targeting “high-quality businesses that have reached strategic, operational or financial inflection points and stand to benefit from [a] hands-on, operationally focused approach.” Calderon says Arecont Vision’s investment banker, Imperial Capital, was instrumental in bringing Turnspire to the table. The Turnspire purchase agreement proposes that the new owner retain the majority of employees, and the overall function and motivation of the company will remain. New levels of outsourcing, new software tools, or other strategies may be implemented to increase efficiency of operations. Focus (and investment) are likely to center on key functions such as engineering, product development and sales. After the acquisition and bankruptcy are completed – in the next several months – Arecont Vision expects to continue to compete based on technology differentiation in the market, rather than on price, says Calderon. Business As Usual Customers and partners see it as a positive step, and they understand that getting rid of the debt burden can only be positive” Calderon declined to be more specific about future plans for the company under the new ownership, who will ultimately decide what those plans are. He did reiterate Arecont Vision’s past successes and expected continuing role in the market. “We are looking to provide the leadership and the type of solution we are known for providing,” he says. “We have come out with some innovative things historically, from megapixel cameras to the first H.264 cameras to the first omni-directional cameras. We have not stopped our innovation, and our intent is to lead the market again with innovative solutions. Another key is to do right by our customers today and in the future, improving customer service, providing better offerings to our customers – that’s what we will be looking to do.” “I’ve had a lot of conversations with customers and partners in the last couple of days,” Calderon says. “I can say the conversations have been encouraging. They see it as a positive step, and they understand that getting rid of the debt burden can only be positive. Customers and partners have offered help, and we’re still closing deals. It’s business as usual.” He noted the company is seeking transparency throughout the process and wants to ‘get in front of’ the information flow, rather than allowing others to drive the narrative.

Inaugurated on May 25, 1999, the Museo Antropológico de la Comunidad de Madrid began construction in 1987. It wasn't until ten years later, in 1997, that the decree establishing the museum was issued, thus formalizing the institution's existence. As part of the museum’s modernization, the client needed an SMD LED solution that includes a glass in front of it to avoid dead pixels and any possible damage or accidents caused by museum visitors. Dahua, together with Epsilon Media, provided an innovative solution that overcame these limitations and optimized the museum experience. Renovation of The Museum The Museo Antropológico de la Comunidad de Madrid was converted from the former Dominican Convent of the Mother of God, built in several phases between the 17th and 18th centuries. As an old establishment, the client wanted to renovate the installation step by step, with the first stage comprised of an LED wall in the main entrance. Their first idea was to install an SMD LED solution with a glass front in order to protect the LED wall and avoid issues with all visitors visiting the museum. Building such a solution is costly and may not be the right solution due to the lack of front-line maintenance. Flip COB Indoor Fine Pixel Pitch LED The Dahua Flip COB Indoor Fine Pixel Pitch LED offers mini flip Chips on Board (COB) technology Together with the Epsilon Media and the Dahua team, the museum evaluated the Dahua Flip COB Indoor Fine Pixel Pitch LED solution in person. After a deliberate discussion, the client agreed that it is the right solution for their facilities. The Dahua Flip COB Indoor Fine Pixel Pitch LED offers mini flip Chips on Board (COB) technology that enables full illumination and softer light without pixel particles, effectively combating digital visual fatigue. Key Features Another notable feature of this LED is its dustproof and anti-fingerprint surface that leaves no visible traces when touched It allows full front maintenance that makes disassembly and maintenance highly efficient. With the full control of the ink color parameters on the surface of the light board, the ink color at all angles is guaranteed to be uniform, which helps solve the industry’s issue regarding ink color differences in batches. Other benefits include high contrast of 10,000:1, energy-saving and power-saving capabilities (less than 75 watts per box, 40% lower than other SMD products), and 160° super wide viewing angle. Another notable feature of this LED is its dustproof and anti-fingerprint surface that leaves no visible traces when touched. It is also waterproof and moisture-proof, with a low rate of dead pixels and high hardness against knocks. Doesn’t Require Additional Glass Protection These features effectively meet the requirements of the client regarding additional protection against damage to the LED during operating hours. Dahua continues to drive technological innovation to improve the way people experience history. With the Dahua Flip COB Indoor Fine Pixel Pitch LED and the Quality Service Epsilon Media offered, the Museo Antropológico de la Comunidad de Madrid was able to install an LED wall without the need of additional glass protection, providing an exceptional digital display of historical images inside the museum while enhancing visitor experience and saving costs. Remarks From The Museum Director “With the video wall that Dahua installed for us, we were able to renovate the first unit that was originally there. This type of technology is significantly important in transmitting knowledge about the past. The overall collaboration was very satisfactory,” says Mr. Enrique Baquedano, Director of Museo Antropológico de la Comunidad de Madrid. “The Dahua team was always ready to help whenever we encountered any issue. What’s more, the LED wall is balanced and cohesive with the overall aesthetic of the museum, which is an added bonus,” concluded Mr Enrique.

Ipsotek, an Eviden Business at Atos Group, has announced that it was appointed to provide its AI video analytics technology at the soon-to-be-opened new Midfield Terminal Building at Abu Dhabi International Airport, in Abu Dhabi, UAE. Delivered in partnership with Atlas Security, deployment of Ipsotek’s AI video analytics solutions is anticipated to improve operations, security, and safety across various areas of the Midfield Terminal Building, which is renowned for its iconic architecture and recently gained international attention as a filming location for Mission: Impossible - Dead Reckoning Part One. Advanced surveillance capabilities Ipsotek's AI video analytics technology is well-equipped to address these circumstances Safety and security are clearly paramount in any airport environment, and Ipsotek's AI video analytics technology is well-equipped to address these concerns. The advanced surveillance capabilities of the solution enable operators to detect and identify potential threats across various zones of the airport.  By leveraging intelligent algorithms and machine learning, the system can recognize suspicious behaviors, unauthorized access attempts, or other pre-defined security risks in real-time, allowing for swift response and mitigation. Ipsotek's AI video analytics By leveraging Ipsotek's cutting-edge video analytics solutions, the airport aims to enhance its security measures by effectively detecting abandoned baggage scenarios. Security teams at the airport will be able to quickly identify and respond to any unattended baggage, reducing potential security risks and ensuring a safe environment for passengers and staff. "The deployment of Ipsotek's AI video analytics solutions at the Midfield Terminal Building signifies a significant leap forward for the aviation industry," said Sophiene Marzouk, Ipsotek’s UAE Country Manager. Sophiene Marzouk adds, "We are proud to collaborate with Atlas Security to deliver state-of-the-art technology that enhances operations, security, and safety in one of the world's most iconic airport buildings." Ipsotek's solutions Ipsotek's solutions also play a crucial role in optimizing que management and crowd control “Atlas Security aspires to implement the best technology for security systems in airports and we therefore look to partner with companies bringing innovation in security applications with Artificial Analytics. One company that brings this cutting-edge technology is Ipsotek and Atlas Security is proud to work in the Midfield Terminal Building with Ipsotek,” said Khizer Rehman, Project and Technical Manager at Atlas Security. Ipsotek's solutions will also play a crucial role in optimizing que management and crowd control throughout the airport. By analyzing video feeds, the software can determine que lengths and alert airport staff to potential bottlenecks. New standards for excellence The intelligent system will empower operators to proactively manage queues, allocate resources effectively, and ensure a smooth flow of passengers. As travelers eagerly anticipate the unveiling of the Midfield Terminal Building, the deployment of Ipsotek's AI video analytics solutions is set to improve the airport experience, from safety to security and operations setting new standards for excellence in the aviation industry and turning an impossible mission into a successful deployment.

Robots do monotonous workflows and less pleasant, repetitive tasks with brilliance. Combined with image processing, they become “seeing” and reliable supporters of humans. They are used in quality assurance to check components, help with the assembly and positioning of components, detect errors and deviations in production processes, and thus increase the efficiency of entire production lines. An automobile manufacturer is taking advantage of this to improve the cycle time of its press lines. Together with the latter, VMT Vision Machine Technic Bildverarbeitungssysteme GmbH from Mannheim developed the robot-based 3D measuring system FrameSense for the fully automatic loading and unloading of containers. Pressed parts are thus safely and precisely inserted into or removed from containers. Four Ensenso 3D cameras from IDS Imaging Development Systems GmbH provide the basic data and thus the platform for process automation. Application The actual workflow that FrameSense is designed to automate is part of many manufacturing operations. A component comes out of a machine-here a press- and runs on a conveyor belt to a container. There it is stacked. As soon as the container is full, it is transported to the next production step, e.g., assembly into a vehicle. All these tasks are now to be taken over by a robot with a vision system-a technological challenge Up to now, employees have been responsible for loading the containers. This actually simple subtask is more complex than one might think at first glance. In addition to the actual insertion process, the first step is to determine the appropriate free space for the part. At the same time, any interfering factors, such as interlocks, must be removed and a general check of the “load box” for any defects must be carried out. All these tasks are now to be taken over by a robot with a vision system-a technological challenge. This is because the containers also come from different manufacturers, are of different types, and thus vary in some cases in their dimensions. Positioning of the components For their fully automatic loading and unloading, the position of several relevant features of the containers must be determined for a so-called multi-vector correction of the robot. The basis is a type, shape, and position check of the respective container.  This is the only way to ensure process-reliable and collision-free path guidance of the loading robot. All this has to be integrated into the existing production process. Time delays must be eliminated and the positioning of the components must be accurate to the millimeter. 3D point cloud These point clouds of all four sensors are combined for the subsequent evaluation To counter this, VMT uses four 3D cameras per system. The four sensors each record a part of the entire image field. This can consist of two containers, each measuring approximately 1.5 × 2 × 1.5 meters (D × W × H). Two of the cameras focus on one container.  This results in data from two perspectives each for a higher information quality of the 3D point cloud. These point clouds of all four sensors are combined for the subsequent evaluation. In the process, registrations of relevant features of the container take place in Regions of Interest (ROIs) of the total point cloud. Interference contours  Registration is the exact positioning of a feature using a model in all six degrees of freedom. In other ROIs, interference contours are searched for which could lead to collisions during loading. Finally, the overall picture is compared with a stored reference model. In this way, the containers can be simultaneously checked for their condition and position in a fully automated manner. Even deformed or slanted containers can be processed. All this information is also recorded for use in a quality management system where the condition of all containers can be traced. The calibration as well as the consolidation of the measurement data and their subsequent evaluation are carried out in a separate IPC (industrial computer) with screen visualization, operating elements, and connection to the respective robot control. Image processing solution The entire image processing takes place in the image processing software MSS developed by VMT The main result of the image processing solution is the multi-vector correction. In this way, the robot is adjusted to be able to insert the component at the next possible, suitable deposit position. Secondary results are error messages due to interfering edges or objects in the container that would prevent filling.  Damaged containers that are in a generally poor condition can be detected and sorted out with the help of the data. The entire image processing takes place in the image processing software Multi-Sensor Systems (MSS) developed by VMT. FrameSense is designed to be easy to use and can also be converted to other components directly on site. Robust 3D camera system On the camera side, VMT relies on Ensenso 3D cameras-initially on the X36 model. The current expansion stage of FrameSense is equipped with the Ensenso C variant. The reasons for the change are mainly the better projector performance-thanks to a new projection process-as well as a higher recording speed. In addition, the Ensenso C enables a larger measuring volume. This is an important criterion for FrameSense, because the robot can only reach the containers to be filled up to a certain distance. The specifications of the Ensenso C thus correspond exactly to VMT's requirements, as project manager and technology manager Andreas Redekop explains: "High projector performance and resolution together with fast data processing were our main technical criteria when selecting the camera. The installation in a fixed housing was also an advantage.” Ensenso models Housing of a robust 3D camera system meets the requirements of protection class IP65/67 The Ensenso C addresses current challenges in the automation and robotics industry. Compared to other Ensenso models, it provides both 3D and RGB color information. Customers thus benefit from even more meaningful image data. The housing of the robust 3D camera system meets the requirements of protection class IP65/67.  It offers a resolution of 5 MP and is available with baselines from current to approx. 455 mm. This means that even large objects can be reliably detected. The camera is quick and easy to use and addresses primarily large-volume applications, e.g., in medical technology, logistics, or factory automation. Outlook By automatically loading and unloading containers and the integrated 3D container inspection, manual workstations can be automated with the help of FrameSense. Against the background of the shortage of skilled workers, the system can thus make an important contribution to process automation in the automotive industry, among others. It meets the prevailing challenges of the industry. Ensenso C provides the crucial basis for data generation and exceeds the requirements of many applications. Lukas Neumann from Product Management sees their added value especially here: “The high projector power and large sensor resolutions are particularly advantageous in the field of intralogistics. Here, high-precision components have to be gripped from a great distance with a large measuring volume.” For other stacking or bin-picking applications in classic logistics, he could imagine a similar camera with high projector power but lower resolution and fast recording. So nothing stands in the way of further developments and automation solutions in conjunction with "seeing" robots.

Located in Kerala, India, the Somatheeram Ayurveda Hospital with a Resort Ambiance is the best place for not only visual rejuvenation but also physical and mental rejuvenation. Through Ayurveda, Somatheeram provides a means to shed all worries, anxieties, and illnesses.  With the objective of combining Ayurveda and Tourism, the Somatheeram Research Institute & Ayurveda Hospital was founded in the year 1985, thus making it the world’s first-ever Ayurvedic Hospital in a Resort Ambiance. The Somatheeram Group of Companies came into being with the efforts of the Founder Managing Director, and Architect Mr. Baby Mathew. Challenges Multi-location transmission proves to be an expensive affair if devices are not chosen wisely Somatheeram has multiple resorts, located at different locations. Multi-location communication can prove to be an expensive affair if communication devices are not chosen wisely. Their dependence on public service providers for communication added to their woes of communication between their resorts. To elaborate: Feasibility of existing telephony: Existing telephony became impracticable considering the frequent communication between multi-located properties. Managing different protocols: Interface with different telecom networks requires managing different protocols, which can be cumbersome, time, and energy-consuming. Absence of modern phone features: The lack of advanced features like abbreviated dialing, call pick up, and internal call restriction, prevented them from becoming efficient in day-to-day operations. Transition to modern communication with existing infrastructure: Their investment in existing infrastructure needed protection while also a provision had to be made to modernize the communication using existing infrastructure. Solution The solution offered was based on the fundamentals of multi-location communication solutions Matrix analyzed the challenges of communications for Somatheeram and crafted a solution that was the best fit. The solution offered was based on the fundamentals of multi-location communication solutions. This included the Matrix range of IP-PBX (ETERNITY GENX12S) and GSM Gateway (SIMADO GFX11 and SIMADO GFX11 4G) that optimized the feasibility of communication and helped the firm become more efficient. Solution includes: The Hybrid IP-PBX included ETERNITY GENX12SAC, which enabled them up to 240 Analog users with 64 CO Ports.  Another Hybrid IP-PBX included ETERNITY PENX, which allowed them access to 100 IP Users, onboard IP User Support, LDAP Client support, support of 4G VoLTE ports, COSEC Door Integration, and much more. The GSM gateway included SIMADO GFX11 and SIMADO GFX11 4G which enabled them to make and receive calls from analog extensions. The capability to integrate with almost all industry-pioneering PBXs enabled them a smooth transition to modern communication while maintaining existing infrastructure. Results The solution so implemented enabled all properties to work as a single communication platform and proved to be beneficial for Somatheeram and its properties in more than one way.  The Hybrid IP-PBX enabled them, unified communication facilities like Email to SMS, audio/video calling, unified messaging facilities, and multi-location collaboration features like UC client integration, one-number reach, etc.  The Hybrid IP-PBX also enabled, investment optimization through universal network connectivity, easy and centralized phonebook management through LDAP client support, mobility convenience through 4G VoLTE support, and much more. The GSM/4G gateway enabled them, GSM/4G connectivity to existing infrastructure, hotline extension dialing, emergency number dialing even in the absence of a sim card, etc. through secure network bridging.

The Public Security Department is the law enforcement agency responsible for maintaining public safety, preventing crime, and upholding the law in the region. Established in 1873, the force has been instrumental in maintaining peace and stability in the area, particularly in counter-insurgency operations.  In addition to its core operations, the department conducts community service activities to bridge the gap between the department and the public. The force works closely with other law enforcement agencies to ensure effective coordination and cooperation. Dedicated to upholding the rule of law and protecting the rights of every citizen, it is committed to building a safe and secure environment in the region. Business scenario The lack of centralized monitoring capabilities at the head of the department's office The department is divided into multiple zones, ranges, and districts, with each district housing several branch offices. However, monitoring these dispersed stations posed a challenge. The lack of centralized monitoring capabilities at the head of the department's office and inadequate infrastructure at the department branches could have helped with real-time updates and efficient communication.  To address this, the department aimed to enhance surveillance infrastructure, enable streaming access to all stations and establish a centralized monitoring system. These efforts would improve coordination, data management, and security services for the people of the state. Challenges Monitoring challenge: The stations are dispersed across multiple locations Lack of centralized monitoring capabilities at the head of the department’s office Inadequate infrastructure at the stations for local data recording Hindered real-time updates and efficient communication across the network Solution A total of 70 cameras were installed with varying focal lengths and capabilities to cover 20 branches in the jurisdiction. Based on their requirement the experts suggested high-resolution 5MP bullet cameras with audio support to capture clearer images and for playback and investigation. The motorized varifocal lens and PTZ cameras can be maneuvered remotely for better control over the cameras. Motorized varifocal lens and PTZ cameras can be handled remotely for better control To enable the streaming and recording of footage for a longer duration, eight-channel network video recorders (NVRs) with 1 SATA port (each SATA port supports 10TB storage support) were installed across 20 locations. These NVRs were connected to television screens using HDMI cables, enabling the streaming of live footage at local offices. Matrix SATATYA SAMAS For centralized surveillance, all NVRs related to Matrix SATATYA SAMAS use static public IP. The video management system was connected to the desktop for monitoring purposes and provided Matrix SATATYA VISION 24×7 surveillance on the go.  The Matrix team also provided training to the officials on how to use the video surveillance infrastructure effectively. They were taught to leverage the system's full potential, including best practices for monitoring, managing, and analyzing data captured by the system. Products Offered SATATYA CIBR50FL40CWP: 15 Nos. 5 MP Project Series IR Bullet Camera with 4 mm Fixed Lens and Audio Support SATATYACIBR50MVL12CWP: 40 Nos. 5 MP Project Series IR Bullet Camera with Motorized Varifocal Lens and Audio Support SATATYA PZCR20ML25CWP: 10 Nos. 2 MP Pan-Tilt-Zoom Camera with 25× Optical Zoom and Audio Support Matrix SATATYA NVR0801X: 20 Nos. Eight-channel NVR with 1SATA Port Support Matrix SATATYA SAMAS Video Management System with 70IP Camera Licenses and three Concurrent User Licences Benefits Matrix's video surveillance solution has empowered the department with real-time updates. The robust infrastructure enables centralized monitoring, enhancing public safety and quick response to incidents. Matrix's expertise and technical capabilities have significantly contributed to maintaining law and order in the region.

Gunnebo Entrance Control solutions have been installed at travel software and technology specialist Sabre’s remodeled office in Uruguay, to ensure the safety and well-being of its employees, clients, and visitors. As a global technology company serving the travel industry, Sabre’s innovative software has revolutionized the way personalized travel experiences can be delivered, pioneering to an increasingly digital and interconnected world. Entrance control requirements With its visionary approach and dedication to customer success, its base in Uruguay is currently home to over 800 staff. To help Sabre meet its entrance control requirements, Gunnebo was invited to work with Abelenda Hermanos as a security system supplier to design and install a comprehensive solution, created to optimize access control while maintaining a seamless flow of people. Author's quote By proactively working with Gunnebo Entrance Control we were able to design a system" Says Natalie Sarmiento, Sabre Security & Safety Manager: “Our vision is always to connect people with travel experiences that matter most. And in doing so, our team is the most important part of our business to think differently and make this happen for our customers. We needed to ensure their security on-site in our remodeled office in Uruguay, with the highest standards." He adds, “By proactively working with Gunnebo Entrance Control we were able to design a system that easily blended with its surroundings, while coexisting with the welcoming environment we wanted to create for our employees and our guests. This is something that flows throughout our offices and has been received well by all on site.” Gunnebo's entrance control solutions Gunnebo Entrance Control worked closely with Sabre to create a bespoke entrance control solution, incorporating its latest sleek design SpeedStile FP 1200 EV speed gates, finished in full stainless steel grade 304, to operate six lanes in place. By implementing Gunnebo's entrance control solutions, Sabre has significantly enhanced security measures, reducing the risk of unauthorized access without compromising on speed or esthetic design. Gunnebo SpeedStile system Real benefit of working with the Gunnebo SpeedStile system is the focus on ease of installation" Says Omar Ferrero, Director at Abelenda Hermanos: “It was an absolute pleasure to work with Sabre and install entrance control for the benefit of its staff and guests. The real benefit of working with the Gunnebo SpeedStile system is the focus on ease of installation, together with its use of advanced technology to balance speed, security and design. The finish is stylish and maintains the highest level of safety for all who work and visit the new facilities.” Gunnebo's SpeedStile FP 1200 EV system enhances security and optimizes the flow of people in office environments. The system's high throughput capability ensures efficient traffic management, allowing for swift and smooth access for authorized individuals. Customized security solutions Equipped with intelligent sensors, it provides accurate and reliable entrance control, effectively preventing tailgating. Additionally, the system's customizable design options enable integration with the surrounding architecture, enhancing the esthetic appeal of the new headquarters. Thomas Axelson, Gunnebo Partner Network Manager – LATAM concluded: “The successful installation of Gunnebo’s entrance control solutions at Sabre’s offices in Uruguay highlights our capability to deliver customized security solutions. We will work with our clients and installers right from the initial design stage to project completion to deliver a solution that presents the highest level of security while maintaining a welcoming feel. We are thrilled with the results and proud to support Sabre as they continue their mission to make travel happen across the globe.”

The ability to treat patients in a secure environment is a base requirement of hospitals and other healthcare facilities. Whether facilities are large or small, security challenges abound, including perimeter security, access control of sensitive areas, video surveillance, and even a long list of cyber-risks. We asked this week’s Expert Panel Roundtable: What are the security challenges of hospitals and the healthcare industry?
