Hikvision DS-7616HI-ST 16-channel Digital Video Recorder
Technical Specification
Features:
- Make: Hikvision
- Model code: DS-7616HI-ST
- Channels: 16
- Recording Mode: Real Time / Timelapse / Event
- Hybrid IP inputs: 32
Additional info:
H.264 video compression Third-party network cameras supported Up to 5 Megapixels resolution recording HDMI and VGA output at up to 1920×1080P resolution HDD quota and group management
Read more| Make | Hikvision |
|---|---|
| Manufacturer | Hikvision USA Inc. |
| Category | Video Surveillance>Digital video recorders (DVRs) |
| Model code | DS-7616HI-ST |
| Channels | 16 |
| Recording Mode | Real Time / Timelapse / Event |
| Hybrid IP inputs | 32 |
| Inbuilt Multiplexer | Yes |
| Storage Capacity GB | 4096 |
| Compression Type | H.264 |
| Resolution | 1920 × 1080 |
| Signal Mode | PAL / NTSC |
| External Storage | USB |
| Recording System | HDD |
| Type of Multiplexer Functions | Recording, Playback, Viewing |
| IP Storage rate (fps) | 30 |
| IP Ready | Yes |
| Physical Specifications |
Dimensions mm: 445 × 290 × 45 Weight kg: 2 |
| Electrical Specifications |
Voltage: 12 V DC Power Consumption: 10 W |
| Environmental Specifications |
Operating Temp oC: -10 ~ +55 C (14 ~ 131 F) Operating Humidity %: 10 ~ 90 |
| Additional info |
|
