Hikvision DS-2DF7232IX-AEL(W) 2MP 32× Network IR Speed Dome

Technical Specification

This product model is not available in this region

Hikvision DS-2DF7232IX-AEL(W) 2MP 32× Network IR Speed Dome

Features:

Make: Hikvision
Model code: DS-2DF7232IX-AEL(W)
Series: PTZ Ultra Series
Chip Inch Size: 1/3
Color Type: Color / Monochrome

Additional info:

1/2.8’’ Progressive Scan CMOS, up to 1920x1080 Ultra-low temperature with -40℃ Smart Tracking, Smart Defog 32X Optical Zoom Smart IR, 150m IR distance 3D DNR, 120dB WDR, HLC/BLC IP66 rating Support H.265+/H.265

Contact manufacturer Contact manufacturer

Make	Hikvision
Manufacturer	Hikvision USA Inc.
Category	Video Surveillance>IP Dome cameras
Model code	DS-2DF7232IX-AEL(W)
Series	PTZ Ultra Series
Chip Inch Size	1/3
Color Type	Color / Monochrome
Resolution TVL	2MP
Megapixel	Yes
Dome Type	PTZ
Sensitivity lux	0 ~ 0.05
Pan Speed ^o/ sec	Pan Manual Speed: 0.1° -210°/s, Pan Preset Speed: 280°/s
Indoor/Outdoor	Indoor/Outdoor
Digital (DSP)	Yes
Tilt Speed ^o/ sec	Tilt Manual Speed: 0.1°-150°/s, Tilt Preset Speed: 250°/s
Mount Type	Wall, Corner, Pole
Electrical Specifications	Voltage: 24 V AC & Hi-PoE Power Consumption: 24 VAC：Max. 60W, High-PoE：Max. 50W
Focal length	4.5 ~ 144 mm
Presets	300
Compression	H.264/MJPEG/MPEG4, H.264 encoding with Baseline/Main/High profile
Back Light Compensation	Yes
Auto Gain Control	Yes
White Balance	Yes
Electronic Shutter range	1/1-1/30,000s
Signal Mode	PAL, NTSC
Zoom Ratio	x32
Network Properties	Image Frame Rate: 25 ~ 30 fps
Physical Specifications	Dimensions mm: 245 x 374 Weight g: 6000
Environmental Specifications	Operating Temp ^oC: -40 ~ +65 C (-40 ~ +149 F) Protection: IP66
Additional info	1/2.8’’ Progressive Scan CMOS, up to 1920x1080 Ultra-low temperature with -40℃ Smart Tracking, Smart Defog 32X Optical Zoom Smart IR, 150m IR distance 3D DNR, 120dB WDR, HLC/BLC IP66 rating Support H.265+/H.265
