ANPR Optimized CCTV Camera With HyperSense Technology From Dedicated Micros

Product Profile

Available in both analog and IP models, Dedicated Micros unique HyperSense technology removes all unnecessary detail, including ambient light from a scene leaving only the objects that strongly reflect the IR light emitted by the integrated invisible IR LED pulse. Completely eliminating glare from vehicle headlights and providing a crisp, clear image, Dedicated Micros ANPR optimized cameras speed up ANPR computation and increase read accuracy.

Ideal for deployment in a range of applications including petrol forecourt monitoring and car park barrier control, the range includes dedicated ANPR cameras, designed to capture the plate detail of passing vehicles, and combined ANPR / Overview cameras, to associate colour images of the vehicles with their number plates.


  • Extruded aluminum housing - weatherproof to IP66
  • Integral LED array, 850nm pulse synchronised with camera
  • 18-50mm F1.6 lens with auto-iris
  • Removable IR cut filter
  • 1/3" sensor
  • Sensitivity 1.0 / 0.15lux (40 IRE)
  • Resolution 540TVL
  • Shutter speed 1/1,000s
Read more

Technical Specification

Make Dedicated Micros
Manufacturer Dedicated Micros
Model code DM/PR-1850D-Overview
Series ANPR Optimised Cameras
Chip Inch Size " 1/3
Color Type Color / Monochrome
Resolution TVL 540
Specialist Types Infrared
Auto Iris Yes
Sensitivity lux 0.15
Electrical Specifications Voltage: 24 VAC
Power Consumption: 6.5 W
Focal Length mm 18 ~ 50
Picture Elements HxV 752 x 582
Electronic Shutter range 1/1,000
Video Output 1 Vp-p, 75 Ohms
Physical Specifications Dimension mm: 460 x 150 x 222
Environmental Specifications Operating Temperature oC: -10 ~ +50
Protection: IP66
Additional info Aluminum housing and sunshield included. ANPR software not included. Moving IR cut filter.
