ANPR Optimized CCTV Camera With HyperSense Technology From Dedicated Micros
Product Profile
Available in both analog and IP models, Dedicated Micros unique HyperSense technology removes all unnecessary detail, including ambient light from a scene leaving only the objects that strongly reflect the IR light emitted by the integrated invisible IR LED pulse. Completely eliminating glare from vehicle headlights and providing a crisp, clear image, Dedicated Micros ANPR optimized cameras speed up ANPR computation and increase read accuracy.
Ideal for deployment in a range of applications including petrol forecourt monitoring and car park barrier control, the range includes dedicated ANPR cameras, designed to capture the plate detail of passing vehicles, and combined ANPR / Overview cameras, to associate colour images of the vehicles with their number plates.
Features:
- Extruded aluminum housing - weatherproof to IP66
- Integral LED array, 850nm pulse synchronised with camera
- 18-50mm F1.6 lens with auto-iris
- Removable IR cut filter
- 1/3" sensor
- Sensitivity 1.0 / 0.15lux (40 IRE)
- Resolution 540TVL
- Shutter speed 1/1,000s
Technical Specification
| Make | Dedicated Micros |
|---|---|
| Manufacturer | Dedicated Micros |
| Category | Video Surveillance>Surveillance cameras |
| Model code | DM/PR-1850D-Overview |
| Series | ANPR Optimised Cameras |
| Chip Inch Size " | 1/3 |
| Color Type | Color / Monochrome |
| Resolution TVL | 540 |
| Specialist Types | Infrared |
| Auto Iris | Yes |
| Sensitivity lux | 0.15 |
| Electrical Specifications |
Voltage: 24 VAC Power Consumption: 6.5 W |
| Focal Length mm | 18 ~ 50 |
| Picture Elements HxV | 752 x 582 |
| Electronic Shutter range | 1/1,000 |
| Video Output | 1 Vp-p, 75 Ohms |
| Physical Specifications | Dimension mm: 460 x 150 x 222 |
| Environmental Specifications |
Operating Temperature oC: -10 ~ +50 Protection: IP66 |
| Additional info | Aluminum housing and sunshield included. ANPR software not included. Moving IR cut filter. |
