Hanwha Vision America

Hanwha Techwin Wisenet 7

Product Profile

With its own device certificate issuing system, Root CA, the Wisenet camera lineup offers the highest levels of cybersecurity possible. Secure by Default, Hanwha Techwin’s cybersecurity policy, embeds unique certificates into all products during each step of the development and manufacturing process. This results in a cybersecurity policy that satisfies stringent UL CAP standards as well as our own requirements for product reliability and design innovation.

Read more

Technical Specification

Make Hanwha Vision
Manufacturer Hanwha Vision America
Category Video Surveillance>IP Dome cameras
Model code XNV-9082R
Series Wisenet 7
Chip Inch Size 1/2.8
Color Type Color / Monochrome
Resolution TVL 4K resolution (3840x2160)
HD Yes
Megapixel Yes
Dome Type PTZ
Sensitivity lux 0 ~ 0.05
Indoor/Outdoor Indoor/Outdoor
Digital (DSP) Yes
Electrical Specifications Voltage: 12 V DC / 24 V AC / PoE
Power Consumption: 11.5 W
Focal length 2.8 ~ 8.4 mm
Compression H.265/H.264: Main/High, MJPEG
Back Light Compensation Yes
Auto Gain Control Yes
White Balance Yes
Electronic Shutter range 1/5 ~ 1/12,000sec
Built-in IR LED Yes
Video Output CVBS: 1.0 Vp-p / 75Ω composite
Zoom Ratio x3
Network Properties Interface: RJ-45(10/100/1000BASE-T)
Network Protocols: IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast)
Image Frame Rate: 30 fps
Physical Specifications Dimensions mm: Ø180 x 125
Weight g: 1,900
Environmental Specifications Operating Temp oC: -50 ~ +60 C (-58 ~ +140 F)
Operating Humidity %: 0 ~ 95
Protection: IP66/IP67/IP6K9K, IK10+
Additional info
  • 4K (3840x2160) resolution
  • 3x (2.8~8.4mm) motorized varifocal lens
  • 131 foot IR viewable range for low light/no light monitoring
  • 30fps@all resolutions (H.265/H.264)
  • H.265, H.264, MJPEG codec supported, multiple streaming
  • Day & Night (ICR), extremeWDR, Defog
  • Shock detection, Loitering, Directional detection, Face/Upper Body detection, Fog detection, Audio detection, Digital auto tracking, Sound classification, Tampering
  • Motion detection, Handover, Audio event playback
  • Dual SD/SDHC/SDXC memory slots (Total Maximum 512GB)
  • Hallway view, WiseStream II support, IP67/IP66/IP6K9K, IK10+, NEMA 4X
  • LDC support (Lens Distortion Correction)
  • PoE / 12V DC, Optional 24V AC, Bi-directional audio support
  • 2 configurable I/O ports
  • White camera body
  • Weathercap included
