ComNet CNFE6+2USPOE-S Ethernet Self-managed Switch

Technical Specification

Features:

Make: ComNet
Model code: CNFE6+2USPOE-S
POE: Yes
Dimensions mm: 155 x 135 x 56
Weight g: 900

Additional info:

The ComNet™ CNFE6+2USPOE provides 8 Ethernet ports operating at 10/100Mbps and is designed to combine six electrical ports into a second optical port that forwards this data to the next CNFE6+2USPOE. The optical ports are designed to forward the data from the six electrical ports to the next switch, to a PC, or another Ethernet connection. In addition, the electrical ports can supply up to thirty (30) watts of power (“Power Over Ethernet”) to remote Ethernet devices.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	ComNet
Manufacturer	ComNet Europe Ltd.
Category	Video Surveillance>Switchers & Switches
Model code	CNFE6+2USPOE-S
POE	Yes
Physical Specifications	Dimensions mm: 155 x 135 x 56 Weight g: 900
Electrical Specifications	Voltage: 12 ~ 48 V DC Power Consumption: 5 A
Environmental Specifications	Operating Temperature ^oC: -40 ~ +75 C (-40 ~ +167 F) Operating Humidity %: 0 ~ 95
Analog Switcher Type	Switches
Additional info	The ComNet™ CNFE6+2USPOE provides 8 Ethernet ports operating at 10/100Mbps and is designed to combine six electrical ports into a second optical port that forwards this data to the next CNFE6+2USPOE. The optical ports are designed to forward the data from the six electrical ports to the next switch, to a PC, or another Ethernet connection. In addition, the electrical ports can supply up to thirty (30) watts of power (“Power Over Ethernet”) to remote Ethernet devices.
