ComNet CLFE1UTP 1 Port UTP/twisted Pair Ethernet Extender

Technical Specification

Features:

Make: ComNet
Model code: CLFE1UTP
Transmission type: UTP / CAT 5
Video Inputs: 1
TX/RX: TX

Additional info:

ComNet CLFE1UTP is a 1 port UTP/twisted pair ethernet extender that transmits individual Ethernet data channels with Pass-through PoE over standard UTP cable. The extender extends Ethernet up to 914 m over UTP. The extender's high-data rate is ideal for the high bandwidth requirements of Mega-pixel cameras, multiple IP cameras systems, and cameras requiring jumbo frame transmission. The Symmetric Bandwidth provides consistent upload and download with virtually zero packet loss over the total usable distance.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	ComNet
Manufacturer	ComNet Europe Ltd.
Category	Video Surveillance>Analog Transmission
Model code	CLFE1UTP
Transmission type	UTP / CAT 5
Video Inputs	1
TX/RX	TX
Network Properties	Interface: 10/100BaseT Network Protocols: UDP, TCP/IP, HTTP/HTTPs
Transmission Range m	914
Signal Mode	Ethernet
Physical Specifications	Weight g: 120 Dimensions mm: 30 x 40 x 95
Electrical Specifications	Power Consumption: 1 W Voltage: PoE
Environmental Specifications	Operating Temp ^oC: -40 ~ +75 C (-40 ~ +167 F) Operating Humidity %: 0 ~ 95
Additional info	ComNet CLFE1UTP is a 1 port UTP/twisted pair ethernet extender that transmits individual Ethernet data channels with Pass-through PoE over standard UTP cable. The extender extends Ethernet up to 914 m over UTP. The extender's high-data rate is ideal for the high bandwidth requirements of Mega-pixel cameras, multiple IP cameras systems, and cameras requiring jumbo frame transmission. The Symmetric Bandwidth provides consistent upload and download with virtually zero packet loss over the total usable distance.
