CEM Systems TSR/200/118 emerald TS200f Intelligent Fingerprint Terminal (iCLASS / iCLASS SE)
Technical Specification
- Make: CEM Systems
- Model code: TSR/200/118
- Reader Type: Biometric
- Keypad Integrated: Yes
- LED / Beep: High Intensity multi-color LED indicator
Industry’s most multifunctional access terminal with integrated biometrics Controller, advanced IP card reader and single biometric solution all in one that meets requirements for three stage identity authentication (card, PIN, and biometric verification) Fast card and fingerprint verification, uses 1:1 fingerprint match at the door Secure storage of fingerprints on the central AC2000 server and on the emerald internal database Fingerprint module gives a high resolution scan with FIPS201 approved biometric algorithm Durable enough for indoor or outdoor usage with an IK06 vandal resistance rating, and IP65 dust and water resistant rating User-friendly 4.3” capacitive LCD touch screen Intuitive Graphical User Interface enhancing user experience at the door Scramble keypad option for Personal Identification Number (PIN) Fully integrated VoIP intercom functionality Available with onboard PoE+ technology to power the terminal and additional door furniture PIR motion detection Remote upload of new firmware directly to the reader with on-screen indication Maintenance Information / Security Intelligence Point Ability to display live video at the workstation on intercom request, when interfaced with CCTV system (available with AC2000 v6.7 & upwards) Ability to display advertising/ information announcements and personal messages
Read more| Make | CEM Systems |
|---|---|
| Manufacturer | CEM Systems Ltd |
| Category | Access Control>Access control readers |
| Model code | TSR/200/118 |
| Reader Type | Biometric |
| Keypad Integrated | Yes |
| LED / Beep | High Intensity multi-color LED indicator |
| Color | Black |
| Wiegand Interface | Yes |
| Electrical Specifications | Voltage: 10 ~ 14 V DC |
| Physical Specifications |
Dimensions mm: 240 x 108 x 49 Weight g: 600g |
| Environmental Specifications | Operating Temp oC: -15 ~ +50 C (5 ~ 122 F) |
| Protection | IP65, IK06 |
Product description
CEM Systems Emerald TS200f
The CEM Systems Emerald TS200f is a cutting-edge intelligent fingerprint terminal, seamlessly integrating biometrics with state-of-the-art access control solutions. Designed to meet the demanding needs of high-security environments, this multifunctional device combines a controller, advanced IP card reader, and a single biometric solution into one compact system.
Key Features
- Three-stage Authentication: Supports card, PIN, and biometric verification for enhanced security.
- High-Resolution Fingerprint Scanning: Utilizes a FIPS201-approved algorithm for rapid and accurate fingerprint matching.
- Robust Design: Vandal-resistant (IK06) and dust/water-resistant (IP65), suitable for both indoor and outdoor use.
- Interactive 4.3” Touch Screen: Displays access statuses and predefined messages to enhance user experience.
- Integrated VoIP Intercom: Facilitates two-way communication with AC2000 workstation operators.
- Convenient Power Options: Features onboard Power over Ethernet Plus (PoE+) for streamlined installation.
Ideal Use Cases
The Emerald TS200f is perfect for securing restricted areas in facilities requiring stringent access protocols. It's particularly effective in environments where a biometric layer of security is crucial, such as data centers, airports, and government buildings.
This device also supports off-line card validation, storing up to 123,000 records. Coupled with the AC2000 security management system, it offers additional features like live video integration, checklist mode, and time & attendance tracking, making it a versatile solution for advanced security needs.
